Summary of Contents for SUPAIR STEP Light
- Page 1 User's manual SUPAIR 34 rue Adrastée Parc Altaïs EN-B+ 74650 Annecy - Chavanod FRANCE 45°54.024’N / 06°04.725’E...
- Page 2 Glider user's manual | STEP Light Thank you for choosing to fly our STEP Light. We are delighted to have you on-board to share our passion for paragliding. SUPAIR has been designing, producing and selling accessories for free flying activities since 1984. By choosing a SUPAIR product you benefit from almost thirty years of expertise, innovation and customer care.
-
Page 3: Table Of Contents
Glider user's manual | STEP Light Contents Introduction Flight incidents Technical data Line layout In-flight weight range Materials Equipment overview Measurements tables Setting up the glider Maintenance Pre-flight preparation Recycling Take-off Eco-responsibility Flight characteristics Mandatory checks End of the flight... -
Page 4: Introduction
It also means that it requires a skill level and experience compatible with the wings in that category, which is the upper part of the B-class. It can be used with most harnesses found on the market today. For better inflight comfort and sensations we will advise you to choose the SUPAIR cross or hike &... -
Page 5: Technical Data
Glider user's manual | STEP Light Technical data Glider STEP Light Cell number Flat surface area (m²) 21,5 Span (m) 11,07 11,7 12,17 12,63 Chord (m) 2,54 2,64 2,74 Flat Aspect Ratio Projected surface area (m²) 18,106 20,21 21,90 23,58... -
Page 6: In-Flight Weight Range
Glider user's manual | STEP Light In-flight weight range Weight (kg) STEP Light STEP Light STEP Light STEP Light In-flight weight range (kg) Perfect In-flight weight range (kg) to optimize flight performances OCEAN VOLCANO SUPAIR | STEP Light | page 6... -
Page 7: Equipment Overview
Glider user's manual | STEP Light Leading edge Trailing edge Stabilizer Inner Surface Outer Surface A riser « A » split riser (for Big Ears) B riser C riser Brake line Brake holder Brake handle Riser hook-up loop C-handling bar Pocket with repair kit. -
Page 8: Setting Up The Glider
A,B and C risers as well as the brake lines neatly. Knots or tangles can not be present. Choosing an adapted harness. The STEP Light glider was certified EN B with a EN1651 & LTF certified harness and can therefore be flown with most harnesses models found on the market today. We wil advise you to choose a EN1651 and or LTF certified harness with a built-in dorsal pro- tection system. - Page 9 Glider user's manual | STEP Light Setting up the glider Brake line length fisherman's knot Brake line lengths are set at the factory to allow optimal glider control. However, if they do not suit you they can be adjusted to your liking.
-
Page 10: Pre-Flight Preparation
Glider user's manual | STEP Light Pre-flight preparation The STEP Light wing was designed for for recreational pilots, sportsmen, who want a high performance glider, at the top of the B-category. To discover your new wing, we will advise you to practice groundhandling and conduct your first small flights in calm conditions on a school training hill or a familiar site you are used to flying. -
Page 11: Take-Off
Glider user's manual | STEP Light Take-off Inflating the STEP Light is easy without any hard point. The sequence demands and adaptation to the weather conditions of the day. It is possible to inflate it forward or reversed. Forward launch To inflate the glider grab the upper ends of the "A"... -
Page 12: Flight Characteristics
Here are a few tips to take advantage of your STEP Light wing's performance in flight: In flight, the STEP Light remains homogeneous even in turbulent air. The "Shark Nose" profile remains solid even when accelera- ted. The turn is intuitive and easy to control. -
Page 13: End Of The Flight
Towing The STEP Light wing can be towed up. Fly only with certified gear operated by qualified personal and only after taking a towing clinic. The towing force must correspond to the weight of the equipment, and the pulling sequence can only start when the wing is fully inflated and stable over the pilot's head. -
Page 14: Fast Descents
Glider user's manual | STEP Light FAST DESCENTS The following techniques should only be used in emergencies and require prior training to be safely conducted. Appropriate analysis and anticipation of the conditions will often prevent the need to use fast descent techniques. We will advise you to practice in still air and preferably above water. - Page 15 To prevent excessive stress on the glider we do not recommend combining spiral dives with "Ears". Conforming to the B-class of EN-926-2, the STEP LIGHT glider does not show any tendency to stay in a locked spiral configuration and will return by itself to a normal flying angle in less than three full rotations when the brakes are brought back up.
-
Page 16: Flight Incidents
Glider user's manual | STEP Light Flight incidents Asymmetric collapses Any paraglider may occasionally collapse due to turbulence or a piloting error. In the event of an asymmetric collapse your priority must be to stay clear of the terrain and regain level flight. -
Page 17: Line Layout
Glider user's manual | STEP Light Line layout SUPAIR | STEP Light | page 17... -
Page 18: Materials
Glider user's manual | STEP Light Materials Fabrics Manufacturer Reference Outer surface (main) Porcher Sport Skytex 27gr Classic 2 - 70000 E3H Inner Surface Porcher Sport Skytex 27gr Classic 70000 E71 Supported ribs Porcher Sport Skytex 32 gr Hard finish - 700032E4D... -
Page 19: Measurements Tables
Glider user's manual | STEP Light Measurements tables STEP Light glider size XS Line Check Maintenance Sheet Measurements made from the base of the lines to the base of the wing, WITH risers and soft links, under a 5 kg tension. - Page 20 Glider user's manual | STEP Light Measurements tables STEP Light glider size XS Tolérence +/- 10mm •Lines lenghts under 5 kg of tension Lines individual lenghts A LINES B LINES C LINES D LINES STABILO LINES BRAKE LINES NAME CUT*...
- Page 21 Glider user's manual | STEP Light Measurements tables STEP Light glider size S Line Check Maintenance Sheet Measurements made from the base of the lines to the base of the wing, WITH risers and soft links, under a 5 kg tension.
- Page 22 Glider user's manual | STEP Light Measurements tables STEP Light glider size S Tolérence +/- 10mm •Lines lenghts under 5 kg of tension Lines individual lenghts A LINES B LINES C LINES D LINES STABILO LINES BRAKE LINES NAME CUT*...
- Page 23 Glider user's manual | STEP Light Measurements tables STEP Light glider size M Line Check Maintenance Sheet Measurements made from the base of the lines to the base of the wing, WITH risers and soft links, under a 5 kg tension.
- Page 24 Glider user's manual | STEP Light Measurements tables STEP Light glider size M Tolérence +/- 10mm •Lines lenghts under 5 kg of tension Lines individual lenghts A LINES B LINES C LINES D LINES STABILO LINES BRAKE LINES NAME CUT*...
- Page 25 Glider user's manual | STEP Light Measurements tables STEP Light glider size ML Line Check Maintenance Sheet Measurements made from the base of the lines to the base of the wing, WITH risers and soft links, under a 5 kg tension.
- Page 26 Glider user's manual | STEP Light Measurements tables STEP Light glider size ML Tolérence +/- 10mm •Lines lenghts under 5 kg of tension Lines individual lenghts A LINES B LINES C LINES D LINES STABILO LINES BRAKE LINES NAME CUT*...
-
Page 27: Maintenance
SUPAIR also offers the possibility for its products to be repaired beyond the end of the warranty period. Please contact us either by telephone or by E-mail sav@supair.com in order to receive a quote. -
Page 28: Recycling
Most of them are recyclable. If your STEP Light's life span is over, you can separate all metallic and plastic parts from the cloth and dispose of the rest according to your country's recycling guide lines and requirements. Please contact your local recycling center for more information.. - Page 29 SUPAIR-VLD Parc Altaïs 34 rue Adrastée 74650 Chavanod, Annecy FRANCE info@supair.com +33(0)4 50 45 75 29 45°54.024’N / 06°04.725’E...
