Toto NEOREST 600 Installation Instructions

G Read and follow all of the instructions before installing the NEOREST.
WARNING: Improper use of this product may result in death or serious injury.
CAUTION: Improper use of this product may result in injury or property damage.
This symbol indicates a prohibited use of the product.
This symbol is used to indicate a required step in the use of this product.
Do not use this product in wet or damp
places, such as a shower or bathtub area.
Prohibited (This may cause fire or electrical shock.)
Use of This
Product:
Connect to a proper water source to avoid
the risk of skin irritation.
Always follow the installation instructions
when installing the product. Improper
installation may result in water leakage,
electrical shock or fire.
To prevent sudden water leakage, do not
remove the water supply filter before
closing the water shutoff valve.
1. Do not apply power or supply water to the unit until the
installation process is complete.
2. Do not grasp the toilet bowl connecting hose when mounting
the Washlet main unit onto the toilet bowl.
3. The power voltage is 120V/60Hz. The rated energy consumption
is 1288W. Use wiring and electrical outlet appropriate for this level
of power.

Parts Identification

Package
Washlet Main Unit
36" x 20" x 12"
(920(L) x 506(W) x 300(D)mm)
Remote Controller Parts:
Remote Controller
Remote
Controller Hanger
Flexible connecting hose
Length: 15" (380mm)
Equipped with packing
washer and O-ring. G Instructions Manual
G Installation Instructions
G "How-To" Guide
G Warranty Card
G Flush Label
G Hook
NEOREST 600 Installation Instructions

Safety Instructions

This product should be used with 120V
electrical voltage only to avoid the risk of fire
of electrical shock.
Do not use a damaged plug or cord or insert
into a faulty electrical outlet, as this may
result in fire or electrical shock.
Do not apply force to the flexible connecting
hose or elbow joint as this may result in
water leakage.
When installing the water supply filter, make
sure that it is tightened securely. Improper
installation of the water supply filter may
result in water leakage.

Before Installation

Main Unit Installation
Hardware:
Anti-theft
2 x AA Batteries
remote
control
mounting
blocks
(Instructions included)
3 Screws
Wrench Hose housing
3 Anchor Bolts
Leave with
Owner after
installation.
WARNING:
CAUTION:
4. The power cord is 3 feet (1m) in length. The electrical outlet
should be located on the wall, within reach of the power plug.
5. Use a minimum water supply pressure of 10 PSI (0.07 Mpa)
flowing.
6. The water temperature range should be 0 ~ 35°C (32~95°F).
7. Only use the flexible connecting hose provided in this kit.
Remote control receiver
Motion detection sensor
Main unit
display panel
Washlet water
cover with
screw
shutoff valve
Flexible connecting hose
Power plug
Water shutoff valve
(includes filter)
Always follow the safety precautions/warnings when
using and installing the WASHLET.
Always plug into a grounded (3 prong) plug to
prevent electrical shock in the case of
malfunction or short circuit.
Always insert the power plug securely into
the wall outlet. Failure to do so may result in
fire or electrical shock.
Do not bend or crush the flexible connecting
hose as this may result in water leakage.
Do not lift the Washlet section by grabbing
the seat or lid. The seat or lid may detach
and drop or damage the Neorest.
Features
Remote controller
Main unit
Lid
Motion detection sensor
Main unit controls
2005.2.25 D06698-4
Flush lever
Seat sensor
Wand
Heated toilet seat
Toilet bowl
