Welcome to Follett
Follett equipment enjoys a well-deserved reputation for excellent performance, long-term reliability and outstanding
after-the-sale support. To ensure that this equipment delivers that same degree of service, review this guide
carefully before you begin your installation.
Should you need technical help, please call our Technical Service group at (877) 612-5086 or (610) 252-7301.
Please have your model number, serial number and complete and detailed explanation of the problem when
contacting Technical Service.
Getting Started
After uncrating and removing all packing material, inspect the equipment for concealed shipping damage. All
freight is to be inspected upon delivery. If visible signs of damage exist, please refuse delivery or sign your delivery
receipt "damaged." Follett Customer Service must be notified within 48 hours. Wherever possible, please include
detailed photos of the damage with the original packaging so that we may start the freight claim process.
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.folletthealthcare.com
Follett Advantage
REFVAC4P
Undercounter Refrigerators
REFVAC5P
®
REFADV5-SD
User Guide
Order parts online:
www.follettice.com
01478106R01
Advertisement
Table of Contents
Related Manuals for Follett Advantage REFADV5-SD
Summary of Contents for Follett Advantage REFADV5-SD
- Page 1 If visible signs of damage exist, please refuse delivery or sign your delivery receipt "damaged." Follett Customer Service must be notified within 48 hours. Wherever possible, please include detailed photos of the damage with the original packaging so that we may start the freight claim process.
-
Page 2: Preliminary Information
Preliminary Information Caution Flammable Refrigerant Caution: Risk of fire. DANGER § Risk of fire or explosion. Flammable refrigerant used. Before attempting to install or service this product, all safety precautions must be followed. CAUTION! – Risk of fire or explosion. Dispose of properly in accordance with federal or local regulations. Flammable refrigerant used. -
Page 3: Electrical Specifications
Specifications Capacity 5 cu. ft. Carton Dimension (W x D x H) 26.7" x 28" x 34.6" (67.7 cm x 71.0 cm x 88.0 cm) External Dimension 23.3" x 25.4" x 32" (59.2 cm x 64.6 cm x 81.1 cm) Internal Dimension 18.8"... -
Page 4: Installation
Installation Uncrate REFADV5-SD 1. Remove packing material. 2. Use gloves when handling the carton or the wooden base to protect the hands from splinters. 3. Carefully slide the cabinet off the skid. 4. Remove the protective PVC film from the external surfaces of the unit. 5. -
Page 5: High/Low Temperature Alarm
High/Low Temperature Alarm The temperature alarms are factory set and operate relative to the set point. Normal Operation Index Function Startup Blink Compressor request request Defrost request output on output off — Digit 2 digit LED display with sign (–99 to 99) and decimal point Operation The temperature controller and probe indicate when the refrigeration system is required to turn on and off. -
Page 6: Circuit Diagram
Cleaning Weekly Interior: Using a sponge or soft cloth, clean unit with a non-abrasive, non-chlorinated, all-purpose detergent. Exterior: Wipe exterior with a soft cloth. Semi-Annual Cleaning Cleaning of the condenser at the rear of the unit is recommended at least twice a year. In the case of use in particularly dusty environments, this should be done more frequently (every 3 months). -
Page 7: Troubleshooting
The following is not a malfunction: § It is normal to hear gurgling sounds caused by the flow of refrigerant during each cooling cycle. If problems persist after following this basic troubleshooting guide, call Follett’s technical service group at (877) 612-5086. - Page 8 Refrigerator Assembly REFADV5-SD Undercounter Refrigerator...
- Page 9 Number Description Part Number Door with lock and keys 01462266 Door gasket 01462233 Door assembly (with lock, keys, and door gasket) 01462274 Fan grill, duct plate and evaporator fan 01462258 Silicone blanking cap, outlet pipe cover, outlet pipe 01478064 Bottle holder, glycerin bottle, display probe cover 01478072 Shelf (2) 01462316...
- Page 10 REFADV5-SD Undercounter Refrigerator...
- Page 11 REFADV5-SD Undercounter Refrigerator...
- Page 12 Warranty Registration and Equipment Evaluation Thank you for purchasing Follett ® equipment. We hope you find that our equipment meets or exceeds your expectations, as our goal is to deliver high value products and services that earn your complete satisfaction! Please review the enclosed installation and operations manual.
