Follett Precision series REF4P Installation, Operation And Service Manual
Undercounter refrigerators
Hide thumbs
Also See for Precision series REF4P:
- Installation, operation and service manual (44 pages)
Table of Contents
Advertisement
Following installation, please forward this manual
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
REF4P
to the appropriate operations person.
REF4P and REF5P Precision™ series
Undercounter Refrigerators
Installation, Operation and Service Manual
01041755cvr
REUC235
REF5P
Order parts online:
www.follettice.com
01041755R00
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Follett Precision series REF4P
Summary of Contents for Follett Precision series REF4P
-
Page 1: Undercounter Refrigerators
REUC235 REF4P and REF5P Precision™ series Undercounter Refrigerators Installation, Operation and Service Manual REF4P REF5P 01041755cvr Following installation, please forward this manual to the appropriate operations person. 801 Church Lane • Easton, PA 18040, USA Order parts online: Toll free (877) 612-5086 • +1 (610) 252-7301 www.follettice.com www.follettice.com 01041755R00... -
Page 2: Table Of Contents
Controller Security ..............................8 Changing Temperature Display from C to F ......................8 Sleep Function ...............................8 Temp Log ................................9 Alarming Functions ..............................9 Follett Keypad Lock ............................. 11 Cleaning ..................................12 Annual Cleaning ..............................12 Service ..................................13 Door Gasket Replacement ..........................13 Slide-out Compressor Tray ..........................13 Removing Drawers ..............................13... -
Page 3: Welcome To Follett
Before you Begin After uncrating and removing all packing material, inspect the equipment for concealed shipping damage. If damage is found, notify the shipper immediately and contact Follett Corporation so that we can help in the filing of a claim, if necessary. -
Page 4: Installation
REUC235 Installation Installing Levelers Fig. 1 1. Remove levelers from plastic bag packed inside refrigerator (Fig. 1). 2. Tip refrigerator back and screw levelers in all the way to stop (they will extend 1/8" below base of REF). 3. Adjust levelers as needed to level REF in both directions. To access levelers, remove the lower front panel. - Page 5 REUC235 3. Remove the screw from the white strap on the hinge side of the Fig. 5 wire channel (Fig. 5). Remove the control wire from the channel at the bottom door cap. The wire should be left hanging in the center of the door.
- Page 6 REUC235 9. Remove screws and latch from refrigerator cabinet and the lock Fig. 9 from the door (Fig. 9). 10. Support door and remove screws attaching hinge to refrigerator Fig. 10 cabinet and remove the door (Fig. 10). 11. Cover hinge screw holes with screws removed from opposite side of door and door frame.
-
Page 7: Installing Glycerine Solution In Product Simulation Bottle
REUC235 Installing Glycerine Solution in Product Simulation Bottle Fig. 12 1. Remove the bottle from the bracket located in the upper left side of the refrigerator (Fig. 12). 2. Remove the top and fill the bottle with a 50/50 solution of glycerine and water. -
Page 8: Controller Operation - Precision
If this set point does not meet your specific application needs, instructions for changing the set point are found below. Note: Follett presets its refrigeration system to hold product temperature at approximately 40 F (4.4 C). If you are using this in a food service application, and installing in accordance with NSF, you must set the control set-point to 38 F (3.3 C). -
Page 9: Temp Log
REUC235 Temp Log High and low log display 1. Press the UP arrow to display the highest temperature the refrigerator has recorded since last reset or power cycle. 2. Press the DOWN arrow to display the lowest temperature that the refrigerator has recorded since last reset or power cycle. - Page 10 REUC235 Advanced Settings The refrigerator can be further customized through the first level (L1) and second level parameters (L2) in the chart below. 1. Press and hold SET and UP arrows simultaneously until L1 is displayed. 2. Use the UP and DOWN arrows to navigate the parameters. When the desired parameter is displayed, press SET.
-
Page 11: Follett Keypad Lock
REUC235 Follett Keypad Lock Default user passcode for first-time users User Code 01 is factory set by default to 1 2 3 4 5 6. User Codes 01 to 40 do not have any codes set up and are available for user-programming. -
Page 12: Cleaning
REUC235 Cleaning Interior: Using a sponge or soft cloth, clean unit with a non-abrasive, non-chlorinated, all-purpose detergent. Exterior: Wipe exterior with a soft cloth in the direction of grain as needed. Stainless steel polish may be used to enhance the finish of the unit. Annual Cleaning Fig. -
Page 13: Service
5. Adjust latch and or striker as necessary for proper door closure. Slide-out Compressor Tray Fig. 14 Follett’s slide-out compressor tray allows technicians to partially slide the condensing unit from the freezer back without cutting refrigerant lines. 1. Remove rear panel (Fig. 14.1). -
Page 14: Controller Replacement
REUC235 Controller Replacement Wiring Diagram 120VAC FZR SERIES ONLY 120VAC 12VDC REF4P and REF5P Undercounter Refrigerators... -
Page 15: Refrigeration System
This change can adversely affect the performance of your refrigerator. Therefore, Follett recommends that if hoses are ever connected to the refrigeration system for service, the refrigerant should be recovered, the system evacuated, and recharged by weighing in the correct refrigerant charge. -
Page 16: Compressor Information
Recover, evaluate and weigh in correct charge. Plugged capillary tube. Replace capillary tube and filter drier. Inefficient compressor. Consult technical services. If problems persist after following this basic troubleshooting guide, call Follett’s technical service group at (877) 612-5086. REF4P and REF5P Undercounter Refrigerators... -
Page 17: Accessory Installation
REUC235 Accessory Installation The following instruction sheets are available in the download section of the Follett website (www.follettice.com). Temperature Surveillance Module Accessory (P/N 00168674) § Reference instruction 00168609 (packed with module) Pedestal Base (P/N 01059112) § Reference instruction 01062488 (packed with base) Stacking Kit (P/N 00926618) §... -
Page 18: Replacement Parts
REUC235 Replacement Parts Evaporator Reference # Description Part # Evaporator REF fan motor with hardware 01053818 Evaporator cover REF4P/FZR4P 01049915 Evaporator cover REF5P/FZR5P 01049881 Condensate pan 01012061 Not shown Thermal break cover REFP/FZRP (set of 6) 01053925 Shelf support REF4P/FZR4P 01062785 Shelf support REF5P/FZR5P 01062793... -
Page 19: Condensing Unit
REUC235 Condensing Unit Reference # Description Part # 0104175516 Compressor, NF7CLX 01062389 Condensing unit 01035104 Condenser fan motor 01062363 Condenser fan blade 01062371 Filter drier cap tube 010340799 Compressor start components 01053842 Not shown REF4P and REF5P Undercounter Refrigerators... - Page 20 REUC235 0104175518 REF4P and REF5P Undercounter Refrigerators...
-
Page 21: Hardware
REUC235 Hardware Reference # Description Part # Façade, basic controller with hardware 01053586 Not shown Façade, basic controller with key pad & hardware 01053594 Not shown Façade mounting bracket 01062702 Hinge top, with spring assembly & hardware 01053677 Hinge bottom 00940478 Not shown Hinge kit, top &... -
Page 22: Hardware And Electrical Components
REUC235 Hardware and Electrical Components Reference # Description Part # Not shown Main control board 01062934 Not shown Main control board with keypad 01062959 Not shown Keypad driver board 01034735 Not shown Compressor/defrost relay 01053867 Not shown Temperature probe 01053883 Not shown Refrigeration schrader valve caps 206230... - Page 23 REUC235 REF4P and REF5P Undercounter Refrigerators...
- Page 24 REUC235 Follett is a registered trademark of Follett Corporation, registered in US. 801 Church Lane • Easton, PA 18040, USA 01041755R00 Toll free (877) 612-5086 • +1 (610) 252-7301 © Follet Corporation 3/14 www.follettice.com...
