Yakima CopperHead Instructions Manual

WHEEL STRAP (1X)
END CAP (1X)
LOCKING SKEWER (1X)
DESIGNED FOR FORKS
WITH SAFETY TABS.
OFF-ROAD DRIVING IS
NOT RECOMMENDED.
IMPORTANT WARNING
IT IS CRITICAL THAT ALL YAKIMA RACKS AND ACCESSORIES BE PROPERLY AND SECURELY ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD RESULT IN AN AUTOMOBILE
ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH TO YOU OR TO OTHERS. YOU ARE RESPONSIBLE FOR SECURING THE RACKS AND ACCESSORIES TO YOUR CAR,
CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR, AND DAMAGE. THEREFORE, YOU MUST READ AND
UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS SUPPLIED WITH YOUR YAKIMA PRODUCT PRIOR TO INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS
AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A
PROFESSIONAL INSTALLER.
1033568B - 1/15
CARRIAGE BOLT (1X)
SNAP AROUND (1X)
HEX KEY (1X)
WRENCH (1X)
Forks with
Safety Tabs
COVER (1X)
Type of
POD
SCREWS
(3X)
*CROSSBAR SPREAD
Your crossbar spread is
Min. - Max.
Crossbar
Rack
Spread*
Load
1 or 2 16" - 42"
bikes 41cm - 107cm
3 or more 18" - 42"
bikes
46cm - 107cm
DO NOT EXCEED RACK WEIGHT LIMITS!
the distance between
the crossbars.
Part #1033568 Rev.B
Limits
16" (41cm)
spread =
30 lbs./bike
14 kg/bike
35 lbs./bike
16 kg/bike
