Page 1
WaShER (2x) Warranty registration on-line at: Yakima.com Important warnIng t Is crItIcal that all yakIma racks and accessorIes be properly and securely attached to your vehIcle mproper attachment could result In an automobIle accIdent and could cause serIous bodIly Injury or death to you or to others...
Page 2
attaCH tonguE to maIn aSSEmBLy. • Insert bolt through washer, and through holes on tongue and main assembly. • Install second washer and nyloc nut. • Tighten with supplied align holes on tongue assembly wrenches. with holes on main assembly. For 1 1/4" HItCH onLy: rEmovE tHE HItCH adaptEr. For 2" HItCHES SkIp tHIS StEp and proCEEd to StEp 3. • Remove the set screw.
Page 3
FLIp outErmoSt Support tuBE. • Using supplied wrench remove both sets of bolts, washers, and lock washers. Set aside. • Remove support tube. • Rotate support tube 180°. place rotated support tube back on bracket. align holes. Secure support tube using supplied wrench. fasten and tighten both sets of bolts, washers, and lock washers.
Page 4
InStaLL wHEEL trayS. pull wheel hoop apart. put in place around wheeltray as shown below. Insert into opening of tube. • Insert cap screw Release letting wire rest in through washer, and hole, and slot of wheeltray. through holes on tube. • Install second washer and nyloc nut.
Page 5
Load your BIkES. • Load heaviest bike first. Load it closest to the vehicle. • Set your bike in place. • Loosen sliding wheel tray, and adjust if necessary. • Tighten knob. SECurE tHE Hook. SECurE rEar wHEEL Strap. feed the strap through the spokes of compress the wheel.
Page 6
StickUp up. be sure it locks into upright position. now that you’ve installed your Yakima StickUp take a moment to enjoy your beverage of choice. • Do not drink Use the built in alcohol and drive.
Page 7
7:00 am to 5:00 pm pST This product is covered by YakIMa’s “Love It Till You Leave It” Limited Lifetime Warranty To obtain a copy of this warranty, go online to www.yakima.com or email us at yakwarranty@yakima.com or call (888) 925-4621 k E E p ...
