Yakima Landing Pad 7 Instructions Manual

Maximum
weight
Weight & load
limits are
determined by
the customer/
installer and will
vary depending
upon the
placement of the
Landing Pads
and the strength
& construction of
the material
they are
attached to.
RECOMMENDED TOOLS:
Tape measure, #2 pencil, drill, drill bits from 1/8" to 25/64", drill stop or masking tape, punch, touch-up paint and eye protection.
TO BEGIN, ASSEMBLE THE CONTROL TOWERS ONTO THE CROSSBARS:
Open Control Towers
1033034B-1/12
Landing Pad #5
Landing Pad #7
Using the wrench
provided in Control Tower
carton, loosen towers.
Be careful to keep the bars horizontal; the
loose towers could slide from the bar and fall.
Slide two towers onto each crossbar. Do
not tighten.
IMPORTANT WARNING!
IT IS CRITICAL THAT ALL YAKIMA
RACKS AND ACCESSORIES BE
PROPERLY AND SECURELY
ATTACHED TO YOUR VEHICLE.
IMPROPER ATTACHMENT COULD
RESULT IN AN AUTOMOBILE
ACCIDENT, AND COULD CAUSE
SERIOUS BODILY INJURY OR
DEATH TO YOU OR TO OTHERS.
YOU ARE RESPONSIBLE FOR
SECURING THE RACKS AND
ACCESSORIES TO YOUR CAR,
CHECKING THE ATTACHMENTS
PRIOR TO USE, AND
PERIODICALLY INSPECTING THE
PRODUCTS FOR ADJUSTMENT,
WEAR, AND DAMAGE.
THEREFORE, YOU MUST READ
AND UNDERSTAND ALL OF THE
INSTRUCTIONS AND CAUTIONS
SUPPLIED WITH YOUR YAKIMA
PRODUCT PRIOR TO
INSTALLATION OR USE. IF YOU DO
NOT UNDERSTAND ALL OF THE
INSTRUCTIONS AND CAUTIONS,
OR IF YOU HAVE NO
MECHANICAL EXPERIENCE AND
ARE NOT THOROUGHLY FAMILIAR
WITH THE INSTALLATION
PROCEDURES, YOU SHOULD
HAVE THE PRODUCT INSTALLED
BY A PROFESSIONAL INSTALLER
SUCH AS A QUALIFIED GARAGE
OR AUTO BODY SHOP.
Part #1033034 Rev.B
