User's Guide
DRV84x2_DRV82x2_DRV89x2-EVM User's Guide
This document is provided with the DRV84x2_DRV82x2_DRV89x2-EVM User customer evaluation module
(EVM) as a supplement to the DRV8462, DRV8962, and DRV8262 data sheets. This user's guide details the
hardware implementation of the EVM and how to install the software packages.
If you ordered a DRV8452EVM use hardware files for DRV8462EVM.
At the moment the silk screen has the following errata.
•
The Silk screen says OUT3, it should say OUT4
•
The Silk screen says OUT4, it should say OUT3
1
Introduction.............................................................................................................................................................................2
1.1 Overview............................................................................................................................................................................
Scope............................................................................................................................................................2
2 Jumpers Table and Setup......................................................................................................................................................
3 Hardware Setup....................................................................................................................................................................
5 GUI Operations DRV8462.....................................................................................................................................................
6 GUI Operations DRV8962.....................................................................................................................................................
7 GUI Operations DRV8262.....................................................................................................................................................
8 Updating Firmware...............................................................................................................................................................
9 Evaluation Hardware Overview...........................................................................................................................................
Trademarks
All trademarks are the property of their respective owners.
SLOU558 - AUGUST 2022
Submit Document Feedback
ABSTRACT
Note

Table of Contents

Application...............................................................................13
Copyright © 2022 Texas Instruments Incorporated
DRV84x2_DRV82x2_DRV89x2-EVM User's Guide
Table of Contents
2
3
10
17
27
29
31
32
1
