Service Manual
Room Air-conditioner indoor units
Console Type
OPERATION AND INSTALLATION MANUAL
AF072XCBAA
AF092XCBAA
AF122XCBAA
AF142XCBAA
No.0010573520
Before using t he air condit ioner, please read t his manual carefully.
Please keep t his manual properl y for future use.
E
CONTENTS
Cautions...................... . ...........................1-4
Parts and Funct ions ....... ................................5-8
Operation... ....... ........ ........ .................... 9-14
M a i n te n a n ce . . . . . . . . . . .. . . . . . . .. . . . . . . .. . . . . . . . . . . . . 1 5
Tr ou b l e s h o o t i n g. . . . . . . .. . . . . . . .. . . . . . . . . . . . .
. . . . 1 6
Advertisement
Table of Contents
Related Manuals for Haier AF072XCBAA
Summary of Contents for Haier AF072XCBAA
-
Page 1: Table Of Contents
Room Air-conditioner indoor units Console Type OPERATION AND INSTALLATION MANUAL AF072XCBAA AF092XCBAA AF122XCBAA AF142XCBAA No.0010573520 Before using t he air condit ioner, please read t his manual carefully. Please keep t his manual properl y for future use. CONTENTS Cautions..1-4 Parts and Funct ions ... -
Page 2: Cautions
Damaged air conditioners are not to be put into operation. In case of doubt, consult your supplier. Use of the air conditioner is to be carried out in strict compliance with the relative instructions set forth in the User's Guide. -
Page 3: Specifications
Cautions Do not obstruct or cover the ventilation grille of the air conditioner. Do not put fingers or any other things into the inlet/outlet and swing louver. Do not allow children to play with the air conditioner. In no case should children be allowed to sit on the outdoor unit. -
Page 4: Safety Instruction
Installation Please call Sales/Service Shop for the Installation. Do not attempt to install the air conditioner by yourself because improper works may cause electric shock, fire, water leakage. Installation in an inadequate place may cause accidents. Do not install in the following place. - Page 5 Cautions Use of Air Conditioner When abnormality such as burnt-small found, immediately stop the operation button and contact sales shop. Connect power supply cord to the outlet completely. STRICT ENFORCEMENT Do not use power supply cord in a bundle. PROHIBITION...
-
Page 6: Parts And Functions
Parts and Functions Indoor unit Remote controller 1.OUTLET 2.CONTROL PANEL 3.INLET 4.FILTER ( inside ) 5.OUTLET TEMP SWING MODE SLEEP HEALTH FRESH CLOCK TIMER HIGH/SO FILTER HEAT LIGHT LOCK RESET CODE... - Page 7 Parts and Functions CAUTION Before opening the front grille, be sure to stop the operation and turn the breaker OFF. Do not touch the metal parts on the inside of the indoor unit, as it may result in injury. ON/OFF button Push once to start operation, push once again to stop it.
- Page 8 (except for TIMER,SLEEP and SWING state). NOTE: 1.Single cooling air conditioner does not have the displays and functions related to heating. 2.This kind of unit does not have the following related functions and displays: 3.HIGH/SO button...
-
Page 9: Remote Controller Operation
Parts and Functions 17.SLEEP Button (The clock must be corrected before setting sleep function) Used to set sleep mode. 18.FAN Button Used to select fan speed:LOW,MID,HIGH,AUTO. 19.TIMER OFF Display 20.TIMER Display 21.FILTER Display When the filter need be cleaned, the sign will appear automatically. -
Page 10: Temperature Setting
+2 C, unit will run in mild DRY mode. In ATUO mode, the temperature setting is not displayed on LCD. In this mode, during running air conditioner will select COOL, HEAT or FAN mode automatically according to the room temperature. -
Page 11: Operation
3. Adjust fan speed Press FAN button. At each press, fan speed changes as follows: HIGH Air conditioner will run at the selected fan speed. When in AUTO mode, unit will adjust fan speed according to room temperature automatically. 4. Unit stop Press ON/OFF button to stop unit. -
Page 12: Sleep Function
Sleep Function Before going to bed you can press down the SLEEP button and the air conditioner will run so as to make you sleep more comfortably. Before using this function, the clock must be set. Use of SLEEP function After the unit's start, set running mode and then press SLEEP button once to make the air conditioner have the previous-set sleep time (first power-on is "1h"). - Page 13 Timer ON/OFF Function Set clock correctly before starting TIMER operation TEMP SWING MODE SLEEP HEALTH FRESH CLOCK TIMER HIGH/SO FILTER HEAT LIGHT LOCK RESET CODE Note: After setting TIMER function, the remote controller displays TIMER time. If you want to see clock time, just press CLOCK button once: clock time will be displayed (if you press the button again continuously, you can adjust clock).
- Page 14 Timer ON-OFF Function Set clock correctly before starting TIMER operation TEMP SWING MODE SLEEP HEALTH FRESH CLOCK TIMER HIGH/SO FILTER HEAT LIGHT LOCK RESET CODE 1.Unit start After unit start, select your desired operation mode (operation mode will be displayed on LCD) 2.TIMER mode selection Press TIMER button on the remote controller to change TIMER mode.
-
Page 15: Operation Hints
Note: When sudden power failure happens during unit operation in power failure resume mode, if the air conditioner is not desired for use in a long period, please shut off the power supply in case that the unit automatically resume operation when power is re-supplied, or press ON/OFFto turn off the unit when power resumes. -
Page 16: M A I N Te N A N
Maintenance Cleaning of the unit Turn off the power switch Take off the air inlet grill First switch off the power supply,take off the screw cap,loosen the screw with cross screwdriver . Clean the filter Use water or vacuum cleaner to remove dust. -
Page 17: Trouble Shooting
When the electric plug is pulled out and reinserted, the protection circuit will work for 3 minutes to protect the air conditioner. During unit operation or at stop, a swishing or gurgling noise may be heard. At first 2-3 minutes after unit start, this noise is more noticeable. -
Page 18: Installation Manual Of Room Air Conditioner
Installation Manual of Room Air Conditioner Fig1 Fig2 Fig3 Tool necessary 1. Screw driver 2. Hacksaw 3. 70mm dia.hole core drill 4. Spanner(dia. 17,27mm) 5. Spanner(14,17,27mm) 6. Pipe cutter 7. Flaring tool 8. Knife 9. Nipper 10. Gas leakage detector or soap water 11. - Page 19 Installation Manual of Room Air Conditioner Fixing of the unit 1. Position of the wall hole Wall hole should be decided according to installation place and piping direction.(refer to installation drawings). 2. Making a wall hole Drill a hole of 120X70mm dia. with a little slope towards outside.
- Page 20 Installation Manual of Room Air Conditioner Piping connection of the indoor unit 1. Arrangement of piping and drainage pipe After opening inlet grill,you will see a control box. Remove the cover before working. Cut away, with a hammer or a saw, the lid for piping according to piping direction.
- Page 21 When connecting indoor and outdoor wire, check the number on indoor and outdoor terminal blocks. Terminals of same number and same color shall be connected by the same wire. Incorrect wiring may damage air conditioner's control or cause operation failure. CONNECT TO...
- Page 22 Installation Manual of Room Air Conditioner Others 1.Power supply requirements: Voltage: single-phase1PH,220-230V*,50Hz Dedicated electrical cable should be installed by a qualified technician in accordance with the state regulation for electrical engineering. The power source must be grounded. A circuit breaker must be installed Electrical cables should be connected by ìYî...
- Page 23 Resumable failures are marked with " ", the others are not resumable failures. Resumable failure will disappear when the failure is eliminated and its failure code will disappear automatically within 30 seconds. But the other failure code will disappear only after the unit starts up once again. When failure occurs, the unit only can receive "OFF"...
