Page 1: Indoor Unit
R410A MULTI SPLIT SERIES ROOM AIR CONDITIONER INSTALLATION MANUAL No.0010578129 Please read this manual carefully before using this air conditioner. Please keep this manual safely for future use. INDOOR UNIT AF092XCERA AF122XCERA... -
Page 2: Table Of Contents
Cautions Parts and Functions Operation hints Maintenance Trouble shooting Installation Manual of Room Air Conditioner 10-16... -
Page 3: Cautions
Damaged air conditioners are not to be put into operation. In case of doubt, consult your supplier. Use of the air conditioner is to be carried out in strict compliance with the relative instructions set forth in the User's Guide. -
Page 4: Specifications
Cautions Do not obstruct or cover the ventilation grille of the air conditioner. Do not put fingers or any other things into the inlet/outlet and swing louver. Do not allow children to play with the air conditioner. In no case should children be allowed to sit on the outdoor unit. -
Page 5: Safety Instruction
Installation Please call Sales/Service Shop for the Installation. Do not attempt to install the air conditioner by yourself because improper works may cause electric shock, fire, water leakage. Installation in an inadequate place may cause accidents. Do not install in the following place. - Page 6 Cautions Use of Air Conditioner When abnormality such as burnt-small found, immediately stop the operation button and contact sales shop. Connect power supply cord to the outlet completely. STRICT ENFORCEMENT Do not use power supply cord in a bundle. PROHIBITION...
-
Page 7: Parts And Functions
"RUN" lamp (Red) It lights up when the compressor (Outdoor Unit) is operating. Befor opening the frontal grille, stop the air conditioner and disconnect the appliance. Never touch the metal pates inside the unit in order to avoid injuries. Remote controller's infrared receiver... -
Page 8: Parts And Functions
Parts and Functions Remote controller's infrared receiver It allows the reception of signals sent by the remote controller. If the signal is received, the unit emits a "bip" confirmation sound. ON/OFF button When the remote controller is not available, press this button to start the unit. The fan speed will be set to "AUTO". -
Page 9: Operation Hints
When sudden power failure happens during unit operation in power failure resume mode, if the air conditioner is not desired for use in a long period, please shut off the power supply in case that the unit automatically resume operation when power is re-supplied, or press ON/OFFto turn off the unit when power resumes. -
Page 10: Maintenance
Maintenance Cleaning of the unit Turn off the power switch Take off the air inlet grill First switch off the power supply,take off the screw cap,loosen the screw with cross screwdriver . Clean the filter Use water or vacuum cleaner to remove dust. -
Page 11: Trouble Shooting
When the electric plug is pulled out and reinserted, the protection circuit will work for 3 minutes to protect the air conditioner. During unit operation or at stop, a swishing or gurgling noise may be heard. At first 2-3 minutes after unit start, this noise is more noticeable. -
Page 12: Installation Manual Of Room Air Conditioner
Installation Manual of Room Air Conditioner Fig1 Fig2 Fig3 Tool necessary 1. Screw driver 2. Hacksaw 3. 70mm dia.hole core drill 4. Spanner(dia. 17,27mm) 5. Spanner(14,17,27mm) 6. Pipe cutter 7. Flaring tool 8. Knife 9. Nipper 10. Gas leakage detector or soap water 11. - Page 13 Fixing of the unit 1. Position of the wall hole Wall hole should be decided according to installation place and piping direction.(refer to installation drawings). 2. Making a wall hole Drill a hole of 120X70mm dia. with a little slope towards outside.
- Page 14 Installation Manual of Room Air Conditioner Piping connection of the indoor unit 1. Arrangement of piping and drainage pipe After opening inlet grill,you will see a control box. Remove the cover before working. Cut away, with a hammer or a saw, the lid for piping according to piping direction.
- Page 15 Installation Manual of Room Air Conditioner Others 1. Power supply requirements: Voltage: single-phase1PH,220-230V~,50Hz Dedicated electrical cable should be installed by a qualified technician in accordance with the state regulation for electrical engineering. The power source must be grounded. A circuit breaker must be installed Electrical cables should be connected by “Y”...
- Page 16 Installation Manual of Room Air Conditioner Wiring of indoor unit Remove air intake screen and take out the front wires. Connect the wires as specified in the above methods and diagrams for indoor unit and wire con- nections. Properly apply capping clips on the wires.
- Page 17 Installation Manual of Room Air Conditioner Indoor unit communication addresses setting CAUTION! FAIL TO DO THIS, THE UNIT WILL NOT WORK. 1.There are two methods to set the communication address A. Use the remote controller(default status in first installation). B. Use dip switches on the indoor unit PCB.
- Page 18 Installation Manual of Room Air Conditioner SW01 1 2 3 4 5 6 7 8 How to check the addresses? When finish all the above works, please power off and power on again to the whole system but set all the indoor units in STANDBY. Then continously press the emergency switch until you hear the buzzer sound 5 times(Pi Pi Pi Pi Pi), and then the LCD display board will show the address of this indoor unit.
- Page 19 HAIER GROUP Qingdao Haier Air Conditioner Electric Co., Ltd. Address: Haier Garden, Qianwangang Road, Economic Development Zone, Qingdao, Shandong 266555, P.R.China Web Site: http://www.haier.com...
