Page 1: Console Type
Room Air-conditioner indoor units Console Type OPERATION AND INSTALLATION MANUAL No.0010577698 Please read this operation manual before using the air conditioner. Please keep this manual carefully and safely. AF072XCEAA AF092XCEAA AF122XCEAA AF142XCEAA... -
Page 2: Table Of Contents
Table of Contents Cautions Parts and Functions Operation hints Maintenance Trouble shooting Installation Manual of Room Air Conditioner 9-14... -
Page 3: Cautions
Damaged air conditioners are not to be put into operation. In case of doubt, consult your supplier. Use of the air conditioner is to be carried out in strict compliance with the relative instructions set forth in the User's Guide. -
Page 4: Specifications
Cautions Do not obstruct or cover the ventilation grille of the air conditioner. Do not put fingers or any other things into the inlet/outlet and swing louver. Do not allow children to play with the air conditioner. In no case should children be allowed to sit on the outdoor unit. -
Page 5: Safety Instruction
Installation Please call Sales/Service Shop for the Installation. Do not attempt to install the air conditioner by yourself because improper works may cause electric shock, fire, water leakage. Installation in an inadequate place may cause accidents. Do not install in the following place. - Page 6 Cautions Use of Air Conditioner When abnormality such as burnt-small found, immediately stop the operation button and contact sales shop. Connect power supply cord to the outlet completely. STRICT ENFORCEMENT Do not use power supply cord in a bundle. PROHIBITION...
-
Page 7: Parts And Functions
Parts and Functions Indoor unit 1.OUTLET 2.CONTROL PANEL 3.INLET 4.FILTER ( inside ) 5.OUTLET... -
Page 8: Operation Hints
Note: When sudden power failure happens during unit operation in power failure resume mode, if the air conditioner is not desired for use in a long period, please shut off the power supply in case that the unit automatically resume operation when power is re-supplied, or press ON/OFFto turn off the unit when power resumes. -
Page 9: Maintenance
Maintenance Cleaning of the unit Turn off the power switch Take off the air inlet grill First switch off the power supply,take off the screw cap,loosen the screw with cross screwdriver . Clean the filter Use water or vacuum cleaner to remove dust. -
Page 10: Trouble Shooting
When the electric plug is pulled out and reinserted, the protection circuit will work for 3 minutes to protect the air conditioner. During unit operation or at stop, a swishing or gurgling noise may be heard. At first 2-3 minutes after unit start, this noise is more noticeable. -
Page 11: Installation Manual Of Room Air Conditioner
Installation Manual of Room Air Conditioner Fig1 Fig2 Fig3 Tool necessary 1. Screw driver 2. Hacksaw 3. 70mm dia.hole core drill 4. Spanner(dia. 17,27mm) 5. Spanner(14,17,27mm) 6. Pipe cutter 7. Flaring tool 8. Knife 9. Nipper 10. Gas leakage detector or soap water 11. - Page 12 Installation Manual of Room Air Conditioner Fixing of the unit 1. Position of the wall hole Wall hole should be decided according to installation place and piping direction.(refer to installation drawings). 2. Making a wall hole Drill a hole of 120X70mm dia. with a little slope towards outside.
- Page 13 Installation Manual of Room Air Conditioner Piping connection of the indoor unit 1. Arrangement of piping and drainage pipe After opening inlet grill,you will see a control box. Remove the cover before working. Cut away, with a hammer or a saw, the lid for piping according to piping direction.
- Page 14 When connecting indoor and outdoor wire, check the number on indoor and outdoor terminal blocks. Terminals of same number and same color shall be connected by the same wire. Incorrect wiring may damage air conditioner's control or cause operation failure. CONNECT TO...
- Page 15 Installation Manual of Room Air Conditioner Others 1.Power supply requirements: Voltage: single-phase1PH,220-230V*,50Hz Dedicated electrical cable should be installed by a qualified technician in accordance with the state regulation for electrical engineering. The power source must be grounded. A circuit breaker must be installed Electrical cables should be connected by ìYî...
- Page 16 Resumable failures are marked with " ", the others are not resumable failures. Resumable failure will disappear when the failure is eliminated and its failure code will disappear automatically within 30 seconds. But the other failure code will disappear only after the unit starts up once again. When failure occurs, the unit only can receive "OFF"...
- Page 17 HAIER GROUP Qingdao Haier Air Conditioner Electric Co., Ltd. Address: Haier Garden ,Qianwangang Road , Economic Development Zone, Qingdao ,Shandong 266500, P.R.C Web Site: http://www.haier.com...
