Important!
When using the equipment, a few safety pre-
cautions must be observed to avoid injuries and
damage. Please read the complete operating
instructions and safety regulations with due care.
Keep this manual in a safe place, so that the in-
formation is available at all times. If you give the
equipment to any other person, hand over these
operating instructions and safety regulations as
well. We cannot accept any liability for damage
or accidents which arise due to a failure to follow
these instructions and the safety instructions.

1. Safety regulations

The corresponding safety information can be
found in the enclosed booklet.
Caution!
Read all safety regulations and instructions.
Any errors made in following the safety regula-
tions and instructions may result in an electric
shock, fi re and/or serious injury.
Keep all safety regulations and instructions
in a safe place for future use.
Special information about the laser
Important: Laser radiation
Do not look into the beam
Laser class 2
VORSICHT ! - LASERSTRAHLUNG !
Nicht in den Strahl blicken!
Laserspezifikation
Laser Klasse 2; LMM650P01
: 650 nm; P
nach EN 60825-1
Protect yourself and your environment from risks
and accidents by taking the appropriate precauti-
onary measures.
•
Never look directly into the laser path.
•
Never direct the laser beam at reflecting sur-
faces or persons or animals. Even a low out-
put laser beam can inflict injury on the eye.
•
Caution: It is vital to follow the work proce-
dures described in these instructions. Using
the equipment in any other way may result in
hazardous exposure to laser radiation.
•
Never open the laser module.
Anleitung_TE_XC_110_SPK1.indb 19 Anleitung_TE_XC_110_SPK1.indb 19
GB
0
- 19 -
•
When the machine is not going to be used
for an extended period of time, the batteries
should be removed.
Use of the batteries
•
Make sure that the On/Off switch for the
laser is set to its "0" position before you
insert the batteries. Inserting the batteries
when the laser is switched on can cause
accidents.
•
If the equipment is not used correctly, the
batteries may leak. Avoid contact with
the battery fluid. If you come into contact
with battery fluid, clean the affected body
part with running water. If you get battery
fluid in your eyes, seek immediate medi-
cal assistance. Escaped battery fluid can
cause skin irritation and acid burns.

2. Layout and items supplied

2.1 Layout (Fig. 1a/1b)
1. Handle
2. On/Off switch
3. Locking button for On/Off switch
4. Locking screw for cutting depth setting
5. Allen key
6. Soleplate
7. Spindle lock
8. Locking screw for parallel stop
9. Laser
10. Additional handle
11. Guard hood
12. Saw blade
13. Adapter for dust extraction system
14. Connection for sawdust extractor
15. Lever for opening the swing guard hood
16. Swing guard hood
17. Parallel stop
18. Screw for securing the saw blade
19. Flange
2.2 Items supplied
Please check that the article is complete as spe-
cifi ed in the scope of delivery. If parts are missing,
please contact our service center or the nearest
branch of the DIY store where you made your
purchase at the latest within 5 work days after
purchasing the article and upon presentation of
a valid bill of purchase. Also, refer to the warranty
table in the warranty provisions at the end of the
operating instructions.
•
Open the packaging and take out the equip-
