m25 tanDem PumP
Dimensions
(continued)
15°
max. displ.
72.1 [2.84]
(2) case outlets
77.2
7/8-14*
[3.04]
case outlet L1
(4) system
ports and
Bypass/check/relief valve
(1) charge
this side for port C
inlet
opposite side for port D
(5/16 internal hex)
Approx. center
7/8-14*
Port A
7/8-14*
Port C
43.2
[1.70]
43.2
[1.70]
7/8-14*
Charge pressure inlet E
7/8-14*
Port D
Series 40 Axial Piston Pumps
Technical Information
Installation drawings

Pump and control

332.5
[13.09]
249.4
[9.82]
211.6
[8.33]
7/8-14*
Case outlet
(alternate) L2
15° 15°
max. displ. max. displ.
Charge
pressure
relief valve
152.4 [6.00]
to C.G.
Bypass/check/relief valve
this side for port A
opposite side for port B
of gravity
(5/16 internal hex)
170.7
[6.72]
133.6
[5.26]
7/8-14*
Port B
*All ports are SAE straight thread o-ring ports per SAE J514, unless otherwise specified.
Shaft rotation is determined by viewing pump from input shaft end.
Contact your SAUER-DANFOSS representative for specific installation drawings.
520L0635 • Rev EH • June 2009
54.9
[2.16]
15°
max. displ.
4.57 R
[0.180]
15.24 dia.
[0.600]
101.6 dia.
[4.00]
Control
trunnions
left side
option DL
13.0
[0.51]
9.4 [0.37]
112.3
[4.42]
19.84 dia.
[0.78]
0.8 R max.
[0.03]
14.27 [0.562] dia.
(2) places
CW
CCW
73.02 [2.875]
(2) places
12.7 [0.50]
Control
min.
trunnions
to shoulder
right side
99.1 88.4
option DR
[3.90] [3.48]
both
sides
45°
15.82 [0.623]
(2) places
Control trunion detail
Dimensions in mm [in]
87.4 [3.44]
(2) places
88.4
[3.48]
P100 611E
