Dimensions - ICP G9MAC Series Installation Instructions Manual

Figure 2

Dimensions

(F/G9MAC)
FURNACE SIZE
0601714 17−1/2 (445)
0602120
0801714 17−1/2 (445)
0802120
1002122
1202422 24−1/2 (622)
6
A B
CABINET
OUTLET WIDTH
WIDTH
15−7/8 (403)
21 (533) 19−3/8 (492)
15−7/8 (403)
21 (533) 19−3/8 (492)
21 (533) 19−3/8 (492)
22−7/8 (581)
Specifications subject to change without notice.
C
BOTTOM
AIR INTAKE
INLET WIDTH
16 (406) 8 3/4 (222)
19−1/2 (495) 10 1/2 (267)
16 (406) 8 3/4 (222)
19−1/2 (495) 10 1/2 (267)
19−1/2 (495) 10 1/2 (267)
23 (584) 12 1/4 (311)
SD5060−4
D
SHIP WT.
LB (KG)
154 (69)
159 (72)
164 (74)
169 (77)
179 (80)
203 (91)
440 01 4201 03
