ICP G9MAC Series Installation Instructions Manual page 43

Downflow Configurations − continued
DOWNFLOW VERTICAL − VENT CONFIGURATION
Requires Accessory Internal Vent Kit
See Specification Sheets for current kit number
Representative drawing only, some models may vary in appearance.
* See NOTES following figures.
Figure 53 Horizontal Left Configurations
HORIZONTAL LEFT − VERTICAL VENT CONFIGURATION
Representative drawing only, some models may vary in appearance.
HORIZONTAL LEFT − LEFT VENT CONFIGURATION
Representative drawing only, some models may vary in appearance.
440 01 4201 03
Horizontal Left Configurations − continued
Representative drawing only, some models may vary in appearance.
* See NOTES following figures.
Figure 54
L11F063
Representative drawing only, some models may vary in appearance.
Representative drawing only, some models may vary in appearance.
* See NOTES following figures.
Specifications subject to change without notice.
HORIZONTAL LEFT − RIGHT VENT CONFIGURATION*
* Requires accessory Internal Vent Kit
Horizontal Right Configurations
HORIZONTAL RIGHT − VERTICAL VENT CONFIGURATION
HORIZONTAL RIGHT − LEFT VENT CONFIGURATION
43
