Improperly installed parts may lead to severe injury or death. Here recommends that all bike
assembly, tuning and repairs be performed by a qualified bicycle mechanic.
Figure 3.1
Use a Phillips or flat screwdriver to balance the brake adjustment.
Turn the screw clockwise on one arm to pull both arms in that direction.
In conjunction with adjusting the cable tension, adjust the screws so
each brake pad has 1-2mm clearance from rim.
Tuck the extra cable behind catch on the brake arm.
Figure 3.2
Balance Brake
Tuck-In Cable
15
