ATTACH THE FRONT WHEEL

❶ Loosen the axle nuts on the front wheel. If there is a washer
inside of the axle nut, it belongs outside of the fork
dropouts.
❷
Important! Be sure the wheel is as centred as possible
between the fork legs.
❸ Place the washer on the axle and slide it up against the fork
drop out. Figure 2.5
❹
wheel remained centered between the fork legs.
❺
needed to be sure the wheel is centered and securely
Figure 2.4
12
3
Clip retaining
washer inserted
into dropout hole Figure 2.5
Fork dropout
Dropout hole
2
Axle
Washer
3
4
Axle nut
Water proof plastic cap
4
3
Figure 2.4
