Compatibility:
• Flush Wood Plus Insert
Packing List:
• Face
• Bypass Handle
Installation
1
Before installing, the insert should be in place with the surround panels attached. If using the decorative
grills, install them prior to attaching the face. Install the face following the directions below.
Page 1 of 2
33 Elite Flush Wood Insert Face
Arched Black 98500901
™
• Emblem
• (2) Nuts
Air Control Handle
Un-Screw the air control handle (with
rod) from the air control.
17601369 - 1/4/12
French Country 98500903
Face Installation:
The face has four hooks that
hang on the cast-iron tabs
near the door hinges. When
installing, make sure the
hooks insert fully and lock
into place.
© Travis Industries, Inc.
Artisan 98500900
