  • Page 1 Product Manual Engine Display and Control J1939 Engines Part Number: MVP-A6300 Revision: 1.0 ______________________________________________________________________________________________________________________________________ Copyright  Controls, Inc. P.O. Box 368 • Sharon Center, OH 44274 Phone 330.239.4345 • Fax 330.239.2845 • www.controlsinc.com...

  • Page 2: Table Of Contents

    CONTROLS, INCORPORATED C O N T R O L S Y S T E M S & S O L U T I O N S TABLE OF CONTENTS PRIOR TO ENGINE START ………………...…………………………………………………………………….….……….……….…………... CAN Bus CONFIGURATION THROTTLE SETTINGS INSTALLATION INFORMATION ……...………………………………...…………..………………………………………………..

  • Page 3: Can Bus Configuration

    CONTROLS, INCORPORATED C O N T R O L S Y S T E M S & S O L U T I O N S Prior to starting the engine, select the proper throttle control mode and parameters required for application.

  • Page 4: Installation Information

    CONTROLS, INCORPORATED C O N T R O L S Y S T E M S & S O L U T I O N S INSTALLATION INFORMATION - 3 -...

  • Page 5: Connector Information

    CONTROLS, INCORPORATED C O N T R O L S Y S T E M S & S O L U T I O N S CONNECTOR INFORMATION - 4 -...

  • Page 6: Engine Harness Connector Information

    CONTROLS, INCORPORATED C O N T R O L S Y S T E M S & S O L U T I O N S ENGINE HARNESS CONNECTOR INFORMATION 21 Pin Connector Function Battery Positive Battery Negative Key On Power...

  • Page 7: Engine Alarms, Codes And Messages

    CONTROLS, INCORPORATED C O N T R O L S Y S T E M S & S O L U T I O N S ENGINE ALARMS, CODES AND MESSAGES Engine ECU Alarm/De-Rate/Shut Downs It is important to understand panel operation with respect to engine safety protections, alarms, and fault codes.

  • Page 8: Active And Stored Engine Ecu Codes

    CONTROLS, INCORPORATED C O N T R O L S Y S T E M S & S O L U T I O N S Indicator Lamps Regen Malfunction Wait-to- Active Lamp Start Lamp Lamp Lamp Engine Engine Alarm/Fault...

  • Page 9: Control Panel Analog And Digital Inputs

    CONTROLS, INCORPORATED C O N T R O L S Y S T E M S & S O L U T I O N S CONTROL PANEL ANALOG AND DIGITAL INPUTS The panel has three digital inputs available to monitor other components, senders or signals. The analog input is preset to fuel level and cannot be configured.

  • Page 10: Menu System

    CONTROLS, INCORPORATED C O N T R O L S Y S T E M S & S O L U T I O N S MENU SYSTEM To Enter Menu System Hold MENU button and press ENTER button. Menu Navigation Press MENU button to scroll menu options.
  • Page 11 CONTROLS, INCORPORATED C O N T R O L S Y S T E M S & S O L U T I O N S Main Menus Main Menus Sub Menus Active Engine Fault Codes View/Scroll Active Fault Codes...
  • Page 12 CONTROLS, INCORPORATED C O N T R O L S Y S T E M S & S O L U T I O N S Configuration Menus Quick Setup Engine Manufacturer TSC Minimum Speed TSC Maximum Speed Performance Display Off/On Eng.
  • Page 13 CONTROLS, INCORPORATED C O N T R O L S Y S T E M S & S O L U T I O N S Maintenance Configuration Service Messages Schedule Selection Schedule Reset Schedule Interval Schedule Warning Schedule Trip...
