Magnetic MHTM FlowMotion mWing Operating Instructions Manual page 40

mWing
Installation and assembly
Key for empty conduit plan
Key number
1
2
3
4
5
6
7
8
9
Table 9:
40
Description
Passage direction 1 from "Paid" to "Unpaid"
Passage direction 2 from "Unpaid" to "Paid"
Empty conduit for external data line
Empty conduit for 230 V
Minimal diameter Ø 40 mm, empty conduit for supply, data and signal
lines
Optional for empty conduit for 230 V
Area for conduits
Distance at a passage width of 900 mm
Distance at a passage width of 600 mm
Key for empty conduit plan
