Technical data
3.1
Dimensions and design
3.1.1
mWing
A
Fig. 1:
A
Installation space for reader without the option of the passage direction display, in-
stallation depth 40 mm
16
1239.5
1300
Dimensions of the mWing (sizes in mm),
X corresponds to the ordered passage width
A
180
X + 360
50
X
A
100
60
