About the user manuals
Product documentation is composed of the following documents.
• Installation Guide (accessory): Provides information about "Precautions", "Precautions for instal-
lation" and the installation method.
• Basic Information (this document): Provides information about "Precautions for use" and "Detail
specifications".
• Operating Instructions (in the following website): Explains how to perform the settings and how
to operate this camera.
https://i-pro.com/global/en/surveillance/documentation_database
"<Control No.: C****>" used in these documents should be used to search for information on our
support website (https://i-pro.com/global/en/surveillance/training_support/support/technical_
information) and will guide you to the right information.
• SDXC/ SDHC/ SD memory card is described as SD memory card.
• The external appearance and other parts shown in this manual may differ
from the actual product within the scope that will not interfere with normal
use due to improvement of the product.
Basic Information
Network Camera
WV-S2272L
Model No.
WV-S2252L
Advertisement
Table of Contents
Related Manuals for i-PRO WV-S2272L
Summary of Contents for i-PRO WV-S2272L
- Page 1 “<Control No.: C****>” used in these documents should be used to search for information on our support website (https://i-pro.com/global/en/surveillance/training_support/support/technical_ information) and will guide you to the right information. • SDXC/ SDHC/ SD memory card is described as SD memory card.
-
Page 2: Table Of Contents
Contents Limitation of liability ........................3 Disclaimer of warranty ........................3 About notations ..........................4 System requirements for a PC ...................... 4 Network security ........................... 5 Precautions for use ........................6 Parts and functions ........................8 Troubleshooting ........................... 12 Detail specifications ........................14... -
Page 3: Limitation Of Liability
IMPROVEMENTS OF THIS PUBLICATION AND/OR THE CORRESPONDING PRODUCT (S). Disclaimer of warranty IN NO EVENT SHALL i-PRO Co., Ltd. BE LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE OF THE PRODUCT, FOR THE CASES, INCLUDING BUT NOT LIMITED TO BELOW:... -
Page 4: About Notations
The following notations are used when describing the functions limited for specified models. The functions without the notations are supported by all models. The functions with this notation are available when using the model WV-S2272L. S2272 The functions with this notation are available when using the model WV-S2252L. -
Page 5: Network Security
Network security As you will use this unit connected to a network, your attention is called to the following security risks. A Leakage or theft of information through this unit B Use of this unit for illegal operations by persons with malicious intent C Interference with or stoppage of this unit by persons with malicious intent It is your responsibility to take precautions such as those described below to protect yourself against the above network security risks. -
Page 6: Precautions For Use
Precautions for use When the product is accessible from the Periodically images on the screen appear to Internet be distorted To prevent unauthorized access, note the following. When the camera is installed in a location where • Leave user authentication turned on. it is subject to small vibrations (for example, when •... - Page 7 Cleaning the lens Router Use a lens cleaning paper (used to clean camera When connecting this product to the Internet, lenses or lenses of spectacles). When using use a broadband router with the port forwarding solvent, use an alcohols solvent and do not use a function (NAT, IP masquerade).
-
Page 8: Parts And Functions
Parts and functions „ Terminals [3] [4] [1] RJ45 Network terminal [2] Power supply terminal (12 V DC)/ Power cord plug (accessory) [3] Audio input terminal [4] Audio output terminal [5] EXT I/O terminals/ EXT I/O terminal plug (accessory) [6] MONITOR OUT terminal (factory shipment: NTSC monitor) The illustration shows the camera with power cord plug and EXT I/O terminal plug attached to it. - Page 9 [2] Power supply terminal (12 V DC)/ Power cord plug (accessory) Connect the output cable of the DC power supply to the power cord plug. IMPORTANT: • Be sure to use the power cord plug provided with this product. • Be sure to fully insert the power cord plug into the power supply terminal (12 V DC). Otherwise, it may damage the camera or cause malfunction.
- Page 10 [5] EXT I/O terminals / EXT I/O terminal plug (accessory) Note: • Off, input, and output of the ALARM IN2 and 3 can be switched by configuring the setting. Refer to the Operating Instructions for further information about the ALARM IN2 and 3 settings (“Off”, “Alarm input”, “Alarm output”...
- Page 11 [6] MONITOR OUT terminal (factory shipment: NTSC monitor) Used to connect a monitor used for adjustments during installation or when performing service. IMPORTANT: • The adjustment monitor is used for checking the adjustment of the angular field of view when installing the camera or when servicing.
-
Page 12: Troubleshooting
Troubleshooting Before asking for repairs, check the symptoms with the following table. Contact your dealer if a problem cannot be solved even after checking and trying the solution in the table or a problem is not described below. Reference Symptom Cause/solution pages When using a PoE device for power supply... - Page 13 Reference Symptom Cause/solution pages • Check the following. • Grounding of the camera, a switching hub or periph- eral devices are not done. • The camera is used near an electrical power line. • The camera is used near a device which produces Audio input contains Installation strong magnetic field or radio waves (such as near a...
-
Page 14: Detail Specifications
Dome radius 41.5 mm {1-5/8 inches} Mass: Approx. 830 g {1.83 lbs} Finish: Main body: Aluminum die cast, i-PRO white Dome cover: Polycarbonate resin, Clear Others: Tamper-resistant enclosure* *1 Refer to our support website <Control No.: C0106> for further information about Power source and Power consumption information. - Page 15 Camera • Image sensor: S2272 Approx. 1/1.8 type CMOS image sensor S2252 Approx. 1/2.8 type CMOS image sensor Effective pixels: S2272 Approx. 8.4 megapixels S2252 Approx. 5.1 megapixels Scanning area: S2272 7.68 mm (H)×4.32 mm (V) {5/16 inches (H) × 5/32 inches (V)} S2252 5.12 mm (H)×3.84 mm (V) {3/16 inches (H) ×...
- Page 16 Fog compensation: On/ Off The level can be set in the range of 0 to 8. (only when Intelligent Auto / auto contrast adjust: Off) Light control mode setting: Outdoor scene/ Indoor scene (50 Hz)/ Indoor scene (60 Hz)/ Fix shutter Shutter speed: [30 fps mode] 1/30 Fix, 3/120 Fix, 2/100 Fix, 2/120 Fix, 1/100 Fix, 1/120 Fix,...
- Page 17 Lens • Zoom ratio: S2272 Optical zoom 2.0× (Motorized zoom / Motorized focus) Extra optical zoom max 6.0× (2.0× – 6.0× when resolution is 1280×720) S2252 Optical zoom 3.1× (Motorized zoom / Motorized focus) Extra optical zoom max 9.3× (3.1× – 9.3× when resolution is 640×360) Digital (electronic) zoom: Choose from 3 levels of ×1, ×2, ×4 Focal length:...
- Page 18 • Network Network: 10BASE-T/100BASE-TX, RJ45 connector Resolution * S2272 H.265/ H.264 [16:9 mode*] *[4:3 mode] is not supported. JPEG (MJPEG) 3840×2160/ 2560×1440/ 1920×1080/ 1280×720/ 640×360/ 320×180 S2252 [16:9 mode] 3072×1728 * / 2560×1440/ 1920×1080/ 1280×720/ 640×360/ 320×180 [4:3 mode] 3072×2304 * / 2560×1920/ 1280×960/ 800×600/ VGA/ 400×300/ QVGA Image compression method:...
- Page 19 Up to 16 camera images can be displayed simultaneously on a multi- screen. (Including the camera itself) Compatible SDXC/SDHC/SD It is recommended to use an SDXC/SDHC/SD memory card for i-PRO memory card * devices. (SD speed class 6 or higher) SDXC memory card:...
- Page 20 *1 H.265/H.264 can be selected for each stream. *2 Used by super resolution techniques. *3 Transmission for 4 streams can be individually set. *4 When recording audio on an SD memory card, only use AAC-LC (Advanced Audio Coding - Low Complexity).
- Page 21 Authorised Representative in EU: i-PRO EMEA B.V. Laarderhoogtweg 25, 1101 EB i-PRO Co., Ltd. Amsterdam, Netherlands Fukuoka, Japan i-PRO EMEA B.V. UK Branch 1010 Cambourne Business Park, https://www.i-pro.com/ Cambridgeshire CB23 6DP © i-PRO Co., Ltd. 2022 N1020-1042 PGQP3079YA...
