About the user manuals
Product documentation is composed of the following documents.
• Installation Guide (accessory): Provides information about "Precautions", "Precautions for instal-
lation" and the installation method.
• Basic Information (this document): Provides information about "Precautions for use", "Parts and
functions" and "Detail specifications".
• Operating Instructions (Refer to the link on the following support website): Explains how to
perform the settings and how to operate this camera.
https://i-pro.com/global/en/surveillance/documentation_database
"<Control No.: C****>" used in these documents should be used to search for information on our technical
information website (https://i-pro.com/global/en/surveillance/training_support/support/technical_information)
and will guide you to the right information.
• microSDXC/ microSDHC/ microSD memory card is described as microSD
memory card.
• The external appearance and other parts shown in this manual may differ
from the actual product within the scope that will not interfere with normal
use due to improvement of the product.
Basic Information
WV-S25700-V2L
Model No.
WV-S25600-V2L
WV-S25500-V3L
WV-S25500-F6L
WV-S25500-F3L
Network Camera
WV-S25700-V2L
Advertisement
Table of Contents
Related Manuals for i-PRO WV-S25700-V2L
Summary of Contents for i-PRO WV-S25700-V2L
- Page 1 “<Control No.: C****>” used in these documents should be used to search for information on our technical information website (https://i-pro.com/global/en/surveillance/training_support/support/technical_information) and will guide you to the right information. • microSDXC/ microSDHC/ microSD memory card is described as microSD memory card.
-
Page 2: Table Of Contents
Contents Limitation of liability ........................3 Disclaimer of warranty ........................3 About notations ..........................4 System requirements for a PC ...................... 4 Network security ........................... 5 Precautions for use ........................6 Parts and functions ........................9 Insert / remove a microSD memory card ..................14 Troubleshooting ........................... -
Page 3: Limitation Of Liability
IMPROVEMENTS OF THIS PUBLICATION AND/OR THE CORRESPONDING PRODUCT (S). Disclaimer of warranty IN NO EVENT SHALL i-PRO Co., Ltd. BE LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE OF THE PRODUCT, FOR THE CASES, INCLUDING BUT NOT LIMITED TO BELOW:... -
Page 4: About Notations
The following items indicate the color of dome cover. The functions with this notation are available when using the model with the i-PRO white body. The functions with this notation are available when using the model with the black body. -
Page 5: Network Security
IMPORTANT: • For information on the operation verification of web browsers, refer to our support website <Control No.: C0132>. • When using a PC that does not meet the above requirements, displaying of images may become slower or the web browser may become inoperable. •... -
Page 6: Precautions For Use
Precautions for use When the product is accessible from the Periodically images on the screen appear to Internet be distorted To prevent unauthorized access, note the following. When the camera is installed in a location where it is subject to small vibrations (for example, when •... - Page 7 Do not use benzine, thinner, alcohol, or any other or construction contractor. types of solvents or detergents. Otherwise, it may cause discoloration. When using a chemical cloth <WV-S25700-V2L><WV-S25700-V2LG> for cleaning, read the caution provided with the <WV-S25600-V2L><WV-S25600-V2LG> chemical cloth product.
- Page 8 AVC Patent Portfolio License Time & date setting It is necessary to set the time & date before THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE putting this product into operation. Refer to the PERSONAL USE OF A CONSUMER OR OTHER Operating Instructions for descriptions of how to USES IN WHICH IT DOES NOT RECEIVE perform the settings.
-
Page 9: Parts And Functions
Parts and functions The following are descriptions when using the model WV-S25700-V2L. „ Cables [1] Ethernet cable (category 5e or better, straight, 4 pairs (8 pins)) [5] 4P alarm cable (WV-QCA501A accessory) [5] EXT I/O cable 2P power cable I/O Cable... - Page 10 [2] Power supply cable / 2P power cable (WV-QCA501A accessory) Connect the output cable of the DC power supply to the 2P power cable. IMPORTANT: • Be sure to use the 2P power cable provided with WV-QCA501A. • Be sure to fully insert the 2P power cable into the power supply cable. Otherwise, it may damage the camera or cause malfunction.
- Page 11 [5] EXT I/O cable / 4P alarm cable (WV-QCA501A accessory) Note: • Off, input, and output of the ALARM IN2 and 3 can be switched by configuring the setting. Refer to the Operating Instructions for further information about the ALARM IN2 and 3 settings (“Off”, “Alarm input”, “Alarm output”...
- Page 12 „ Indicators and buttons SD ON/OFF button SD memory card TELE+AF button INITIAL SET button warning/error indicator 257V2L 256V2L LINK indicator 255V3L ACT indicator SD (MOUNT) indicator WIDE+AF button 257V2L 256V2L 255V3L INITIAL SET button (Initializing / NTSC PAL switch button) Follow the steps below to initialize the network camera.
- Page 13 SD (MOUNT) indicator Lights off → Blinks green → Lights off • When a microSD memory card is inserted and could be recognized Lights off → Lights green • When data can be saved after the microSD memory card is inserted and the SD ON/OFF button is pressed (less than 1 second) •...
-
Page 14: Insert / Remove A Microsd Memory Card
Insert / remove a microSD memory card Note: • Use a microSD memory card dedicated to i-PRO cameras. • Refer to the Operating Instructions on our support website for further information about the microSD memory card settings. „ Insert a microSD memory card Remove the enclosure from the camera. - Page 15 Instructions on our manual website for how to format a microSD memory card. • When some microSD memory cards are used with this product, the product may not work properly or performance deterioration may be caused. Use a microSD memory card dedicated to i-PRO cameras.
-
Page 16: Troubleshooting
Troubleshooting Before asking for repairs, check the symptoms with the following table. Contact your dealer if a problem cannot be solved even after checking and trying the solution in the table or a problem is not described below. Reference Symptom Cause/solution pages When using a PoE device for power supply... - Page 17 Reference Symptom Cause/solution pages • Check the following. • Grounding of the camera, a switching hub or peripheral devices are not done. • The camera is used near an electrical power line. • The camera is used near a device which produces Audio input contains Installation strong magnetic field or radio waves (such as near a...
-
Page 18: Detail Specifications
(excluding an attachment for the conduit portion) Approx. 1.1 kg {2.43 lbs.} (excluding an attachment for the conduit portion) Mass: Finish: Main body: Aluminum die cast, Outer fixing screws: Stainless steel (Corrosion-resistant treatment) Dome cover: PC resin, WV-S25700-V2L, WV-S25700-V2LG, WV-S25600-V2L,WV- S25600-V2LG, WV-S25500-V3L, WV-S25500-V3LG :without ClearSight coating... - Page 19 255V3L 255F6L 5.12 mm (H) × 3.84 mm (V) {3/16 inches (H) × 5/32 inches (V)} Scanning system: Progressive <WV-S25700-V2L><WV-S25700-V2LN><WV-S25700-V2LN1> Minimum illumination: <WV-S25600-V2L><WV-S25600-V2LN> Color: 0.04 lx {0.0037 footcandle} (30IRE, F1.5, Maximum shutter: Off (1/30 s), AGC: 11)* 0.06 lx {0.0056 footcandle} (50IRE, F1.5, Maximum shutter: Off (1/30 s), AGC: 11)
- Page 20 Minimum illumination: <WV-S25700-V2LG><WV-S25600-V2LG> Color: 0.12 lx {0.0112 footcandle} (30IRE, F1.5, Maximum shutter: Off (1/30 s), AGC: 11)* 0.17 lx {0.0158 footcandle} (50IRE, F1.5, Maximum shutter: Off (1/30 s), AGC: 11) 0.011 lx {0.001 footcandle} (50IRE, F1.5, Maximum shutter: max. 16/30 s, AGC: 11)* BW: 0 lx {0 footcandle} (50IRE, F1.5, Maximum shutter: OFF (1/30 s), AGC: 11, when the IR LED is lit)
- Page 21 <WV-S25500-F6L> Minimum illumination: Color: 0.08 lx {0.0075 footcandle} (30IRE, F1.6, Maximum shutter: Off (1/30 s), AGC: 11)* 0.11 lx {0.0103 footcandle} (50IRE, F1.6, Maximum shutter: Off (1/30 s), AGC: 11) 0.007 lx {0.0007 footcandle} (50IRE, F1.6, Maximum shutter: max. 16/30 s, AGC: 11)* BW: 0 lx {0 footcandle} (50IRE, F1.6, Maximum shutter: OFF (1/30 s), AGC: 11, when the IR LED is lit)
- Page 22 Color/BW: Off/ On(IR Light Off)/ On(IR Light On)/ Auto1(IR Light Off)/ Auto2(IR Light On)/ Auto3(SCC) IR LED Light: High/ Middle/ Low/ Off <WV-S25700-V2L><WV-S25700-V2LN><WV-S25700-V2LN1> <WV-S25600-V2L><WV-S25600-V2LN> Maximum irradiation distance: 70 m {Approx. 230 ft} (30IRE)* 50 m {Approx. 164 ft} (50IRE) <WV-S25700-V2LG><WV-S25600-V2LG>...
- Page 23 Video Motion Detection (VMD): On/ Off 4 areas available Scene Change Detection (SCD): On/ Off 1 area available Audio Detection: On/ Off AI Sound classification: Selectable from Gunshot, Yell, Vehicle horn, Glass break Image rotation * 0° (Off)/ 90°/ 180° (Upside-down)/ 270° *1 When the 320x180 resolution is used, the “90°”...
- Page 24 Angular field of view: 257V2L 256V2L [16:9 mode] Horizontal: 52° (TELE) – 101° (WIDE) Vertical: 29° (TELE) – 55° (WIDE) 255V3L [16:9 mode] Horizontal: 33° (TELE) – 103° (WIDE) Vertical: 19° (TELE) – 55° (WIDE) [4:3 mode] Horizontal: 33° (TELE) – 103° (WIDE) Vertical: 25°...
- Page 25 DORI * 257V2L Detect (25 ppm / 8 ppf) 157.5 m {516.6 ft} (TELE) 63.3 m {207.7 ft} (WIDE) Observe (62.5 ppm / 19 ppf) 63 m {206.6 ft} (TELE) 25.3 m {83.1 ft} (WIDE) Recognize (125 ppm / 38 ppf) 31.5 m {103.3 ft} (TELE) 12.7 m {41.5 ft} (WIDE) Identify (250 ppm / 76 ppf) 15.7 m {51.7 ft} (TELE) 6.3 m {20.8 ft} (WIDE)
- Page 26 Image compression method * H.265/ H.264 * Transmission priority: Constant bit rate/ VBR/ Frame rate/ Best effort Frame rate: [30 fps mode] 1 fps/ 3 fps/ 5 fps*/ 7.5 fps*/ 10 fps*/ 12 fps*/ 15 fps*/ 20 fps*/ 30 fps* [25 fps mode] 1 fps/ 3.1 fps/ 4.2 fps*/ 6.25 fps*/ 8.3 fps*/ 12.5 fps*/ 20 fps*/ 25 fps* (The frame rate is limited to “bit rate”.
- Page 27 <Control No.: C0132>. *5 When using MJPEG/JPEG (Refresh interval) only. *6 Use a microSD memory card dedicated to i-PRO cameras. *7 For possible number of images and duration (an indication) that can be saved on the microSD memory card, refer to our support website below.
- Page 28 Authorised Representative in EU: i-PRO EMEA B.V. Laarderhoogtweg 25, 1101 EB i-PRO Co., Ltd. Amsterdam, Netherlands Fukuoka, Japan i-PRO EMEA B.V. UK Branch 1010 Cambourne Business Park, https://www.i-pro.com/ Cambridgeshire CB23 6DP © i-PRO Co., Ltd. 2022 av0322-0 PGQP3421ZA...
