- Page 1 Fire-rated swing door drive unit FDC-B France Operator Manual Original 0547-999/47b 2010.04...
-
Page 2: Table Of Contents
CONTENTS SAFETY ........................2 PRODUCT DESCRIPTION ..................3 • Normal operation....................3 • Control........................3 • Safety functions..................... 4 • Function in the event of a mains failure ..............5 • Function in the event of a fire alarm ..............5 • Fire-protection testing ................... 5 OPERATION AND MAINTENANCE ................. 6 •... -
Page 3: Safety
The manufacturer respectively his distribution partner declines all responsibility for any use outside of the defined application purposes or limits. In order to guarantee a safe and reliable operation of the FDC-B France swing door drive unit, it is absolutely necessary that the assembly, operating, maintenance and repair conditions specified by the manufacturer be fulfilled. If these instructions are neglected,... -
Page 4: Product Description
PRODUCT DESCRIPTION Normal operation The swing door drive unit FDC-B France allows an automatic opening and closing of swing doors. The functional characteristics of the door can be determined by means of the program switch as well as of the internal switches and potentiometers. -
Page 5: Safety Functions
Safety functions Obstruction in opening direction If the door leaf meets an obstacle during the opening motion, the drive unit is stopped. The leaf is closed upon expiration of the hold-open time. The next opening motion is carried out with the programmed opening speed; the leaf moves up to the position of the obstacle and from there - provided that the latter has been removed in the meantime - with reduced speed up to the programmed OPEN position. -
Page 6: Function In The Event Of A Mains Failure
Fire protection testing The FDC-B France swing door drive unit has been tested by the following authoritie, on the basis of the mentioned directive: CNPP... -
Page 7: Operation And Maintenance
We recommend to conclude a maintenance contract with the manu- facturer respectively with his authorized distribution partner. The checking and maintenance work must be performed according to the checklist contained in the control booklet FDC-B France. The correct execution must be con- firmed by the after-sales service technician who enters the date and his signature in the control booklet. -
Page 8: Troubleshooting
TROUBLESHOOTING Malfunction Cause Remedy/action Drive unit does not work Program switch switch to position 1 Mains switch (installed by switch on customers) switched off Power plug pulled out plug in customer's fuse defective replace fire detectors have been actuate the reset triggered key-button Buzzer sounds functional/fatal contact the after- error... -
Page 9: Prolonged Operating Interruption
PROLONGED OPERATING INTERRUPTION If the swing door installation is not going to be used for more than 3 months, it is recommended to pull out the power plug. If, at the moment of taking the installation back into operation, the last check-up dates back to more than one year, the installation must be checked by a competent specialist before it is taken back into operation. -
Page 10: Individual Settings Made By The After-Sales Service
INDIVIDUAL SETTINGS MADE BY THE AFTER- SALES SERVICE... - Page 11 INDIVIDUAL SETTINGS MADE BY THE AFTER- SALES SERVICE...
- Page 12 Gilgen offers you a wide range of drive units; ask your distribution partner! Manufacturer Gilgen Door Systems AG Freiburgstrasse 34 CH-3150 Schwarzenburg Phone 031 734 41 11 Telefax 031 734 43 79 Your after-sales service Handed over to the operator Date ........
-
Page 13: Appendix
Declaration of incorporation EC according to Machinery Directive 2006/42/EC Manufacturer: Gilgen Door Systems AG Freiburgstrasse 34 CH-3150 Schwarzenburg Phone +41 31 734 41 11 Responsible for documents: Beat Binggeli Head of QM Gilgen Door Systems AG Freiburgstrasse 34 CH-3150 Schwarzenburg...
