- Page 1 Swing door drive unit FDC-E Operator manual Original 0547-999/58b 2010.04...
-
Page 2: Table Of Contents
CONTENTS SAFETY ........................2 PRODUCT DESCRIPTION ..................2 • Normal operation....................2 • Control........................2 • Safety functions..................... 3 • Function in the event of a mains failure ..............3 OPERATION AND MAINTENANCE ................. 4 • Safety ........................4 • Care and checking to be carried out by the operator ..........4 •... -
Page 3: Safety
SAFETY The swing door drive unit FDC-E has been designed for the automatic operation of swing doors. For any use outside of the defined application purposes or limits, the manufacturer respectively his distribution agent decline all responsibility. In order to guarantee a safe and reliable operation of the swing door drive unit FDC‑E, it is absolutely indispensable that the conditions prescribed by the manufacturer with regard to installation, operation, maintenance and repair be strictly fulfilled. -
Page 4: Safety Functions
Safety functions Obstruction in opening direction If the door wing encounters an obstacle during the opening motion, the drive unit is stopped. The door wing is closed as soon as the hold-open time has expired. Upon the next opening motion, the door wing moves at the programmed opening speed up to the position where the obstacle has been detected and, provided that the latter has been removed in the meantime, from there at slow speed up to the programmed OPEN position. -
Page 5: Operation And Maintenance
OPERATION AND MAINTENANCE Safety In order to guarantee the safety of the users at all times, the swing door installation must be checked with regard to its operational by a competent specialist prior to the first commissioning and at least once a year during operation! The result must be documented in the control booklet. -
Page 6: Troubleshooting
TROUBLESHOOTING Malfunction Cause Remedy/determination Drive unit does not work Program switch Switch to position 1 Mains switch provided by Switch on customers switched off Power plug pulled out Plug in Fuse (installed by Replace customers) defective Buzzer sounds Functional/fatal Contact the after- error sales service... -
Page 7: Prolonged Operating Interruption
PROLONGED OPERATING INTERRUPTION If the swing door installation is not going to be used for more than three months, it is recommended to pull out the mains plug. If at the moment of recommissioning, the last checkup dates back to more than one year, the installation must be checked by a competent person prior to taking it back into operation. - Page 8 Gilgen offers you a wide range of drive units; ask your distribution partner! Manufacturer Gilgen Door Systems AG Freiburgstrasse 34 CH-3150 Schwarzenburg Phone +41 31 734 41 11 +41 31 734 43 79 www.gilgendoorsystems.com info@gilgends.com Your after-sales service Handed over to the operator Date ........
-
Page 9: Appendix
