  • Page 1 PCE Instruments UK Ltd Units 12/13 Southpoint Business Park Ensign Way, Southhampton Hampshire United Kingdom, SO31 4RF Phone +44(0) 2380 98703 0 Fax +44(0) 2380 98703 9 info@industrial-needs.com www.industrial-needs.com Thermometer with Microprocessor PCE-HPT 1 MANUAL Version 1.0 16.09.2014...
  • Page 2: Table Of Contents

    Manual www.industrisal-needs.com Table Of Contents Introduction ....................... 2 Delivery Content ..........................2 Safety Precautions ....................2 Warning symbols ..........................2 Warning notices ..........................3 Technical Specifications .................... 3 Detailed description of device ................... 4 Pins of connection socket for temperature sensor ................. 4 Display ............................
  • Page 3: Introduction

    The microprocessor thermometer features an internal data logger with an adjustable measurement interval. Delivery Content 1 x microprocessor thermometer PCE-HPT 1 1 x PT 100 sensor 1 x USB cable 1 x software...
  • Page 4: Warning Notices

    Manual www.industrisal-needs.com Warning notices This device is only designed for the applications mentioned in this manual. In case the device is used for any other application than these, it might lead to hazardous situations. Do not expose the device to extreme temperatures, direct sunlight, extreme air humidity or liquids.
  • Page 5: Detailed Description Of Device

    Manual www.industrial-needs.com Detailed description of device Fig.1 Connection socket for temperature sensor Display Power-key / key for display lights Button for deviation measurement (REL) Button for data recording (REC) Key for MIN / MAX function (MIN / MAX) Key for Data Hold function (HOLD) Switch for temperature unit (°C / F) Interface for connection to computer (10)
  • Page 6: Display

    Manual www.industrisal-needs.com Display Symbol Explanation The battery state is low. No precise operation! Indicating minimum value Indicating maximum value HOLD The data HOLD function is activated The function “automatic switch-off is activated The data is being recorded The function “deviation measurement” is activated °C F Temperature unit °C or Fahrenheit A temperature under 0 is being indicated...
  • Page 7: Switch Temperature Unit

    Manual www.industrial-needs.com Switch temperature unit The device is set by the manufacturer on °C. To switch to Fahrenheit, press the “°C/F“- button. The device will save your settings even, if it is switched off. Data Hold function You can freeze the current measurement values by pressing the “HOLD” key. The display will then indicate “HOLD”.
  • Page 8: Change The Memory Interval

    Manual www.industrisal-needs.com Raise and decrease their value by pressing the “REC”- or the “°C/F”-button, unit the correct day is indicated. Confirm your selection by pressing the “REL”-button. Now the two ciphers on the left will be blinking. Now you can set the hour by pressing the “REC” or the “°C/F”-button, until you have the correct day.
  • Page 9: Return To Initial Settings

    Manual www.industrial-needs.com Use the “REC” (raise) or the “°C/F” (decrease) button to adjust the indicated value to the actual reference value. Confirm the selection by pressing the “HOLD”-button twice. Note: You can cancel the process at any time by pressing the Power button ( 5.16 Return to initial settings Switch on the device while pressing “REL”...
  • Page 10 Manual www.industrisal-needs.com After completing the installation, please check the device manager under the system settings to see under which COM-Port the device is listed (e.g. the example below is the COM4 Port). After completing the installation, the device can be connected via its USB cable to a computer. Start the software and select the correct COM Port in the Drop-Down menu.
  • Page 11: Main Menu And Buttons

    Manual www.industrial-needs.com Main menu and buttons Open = retrieve data from hard drive Save = Save data on hard drive Print = Send current table of data to printer Pause = Stop the data record Run = Start the data recording Output to Graph = Send table of data to further graphs.
  • Page 12: Data Logger

    Manual www.industrisal-needs.com Data logger In order to transfer the data from the device’s memory to the computer, press the button “data logger”. Thus a progress beam will indicate the state of the data transfer. After a successful transfer of the data, the number of transferred data sets will be indicated at the left side of the display with their parameters (time and date of start, sampling rate …).
  • Page 13: Maintenance And Cleaning

    Manual www.industrial-needs.com Maintenance and Cleaning Change battery Warning: To avoid incorrect measurements and any damages caused by that, please charge the battery immediately when the battery symbol is indicated on the display. To change the batteries, switch off the battery, remove the cover of the battery compartment at the back of the device and change the batteries.
