- Page 1 Hygrometer PCE-EV-KIT 3 Data Logger HYGRO THERMOMETER PCE-330...
-
Page 2: Table Of Contents
Hygro-Thermometer PCE-330 CONTENTS TITLE PAGE 1. SAFETY INFORMATION…………………………………………………………………. 2 2. GENERAL DESCRIPTION………................2 3. FEATURE……………………….…………………............2 4. SPECIFICATIONS……………………………………..……………………………... 2 5. SYMBOL BUTTONS AND FUNCTIONS……………………………......6. DATA LOGGER………………………………………………………………………….… 7 7. SETTING THE TIME……………………………………………………………………… 8 8. POWER PREPARATION ……….………………………………………………………... 8 9. COMMUNICATION WITH A PC…………………………………………………..……. .. -
Page 3: Safety Information
Hygro-Thermometer 1. SAFETY INFORMATION Read the following safety information carefully before attempting to operate or service the meter. Use the meter only as specified in this manual; otherwise the protections provided by the meter may be impaired. ENVIRONMENT CONDITIONS: Altitude up to 2000 meters ... - Page 4 Hygro-Thermometer Relative humidity range: 0 to 100%RH Temperature range: -20 to 60°C (- 4 to 140°F) Dew point temperature range: -20 to 60°C (- 4 to 140°F) Resolution: 0.1%RH, 0.1°C, 0.1°F Accuracy: (at 23°C) <Probe: RP-32> <10%RH, >90%RH ±4.0%RH 10%RH to 90%RH ±2.0%RH -20 to 60°C (-4 to 140°F) ±0.8°C (±1.5°F)
-
Page 5: Symbol Buttons And Functions
Hygro-Thermometer 5. SYMBOL BUTTONS AND FUNCTIONS : Low battery indicator : Auto power off indicator : Minimum / maximum indicator : Relative Humidity reading : Recording data logger indicator : Dew point temperature : Data hold indication : Month-day : Hour: minute : Temperature reading : Temperature measurement units... - Page 6 Hygro-Thermometer FUNCTIONS: ○ Sensor probe ○ Display screen ○ Power / Backlight button Power on/off: Press the button to turn on the unit. To turn the unit off, press and hold button down until the screen shows “OFF 3, 2, 1, 0,” then the LCD screen goes off. Note: When the unit is on, the LCD will show the following initial information before entering the ...
- Page 7 Hygro-Thermometer To start: (1) Press button. MAX symbol lights up on LCD, the reading shows the maximum data. (2) Press button again to show minimum data; the MIN symbol lights up on LCD. (3) Press button again, the MAX and MIN symbol blinks together. The reading shows present humidity and temperature.
-
Page 8: Data Logger
Hygro-Thermometer 6. DATA LOGGER This section will explain how to store data (data logger) in memory and how to recall data from memory. 6.1 SETTING INTERVAL TIME FOR DATA STORING: (1) Turn off the unit. (2) Enter SETUP mode by pressing and holding button and then power button to turn on the unit. -
Page 9: Setting The Time
Hygro-Thermometer 7. SETTING THE TIME The unit incorporates a clock so that the data logger function can also record the data and time along with the measurement value in the memory. 7.1 SETTING DATE AND TIME: (1) Turn off the unit. (2) Enter SETUP mode by pressing and holding button and then power button to turn on the unit. -
Page 10: Communication With A Pc
Hygro-Thermometer 9. COMMUNICATION WITH A PC Users can transfer data from the built-in memory on the instrument to a PC through SE318 software. The communication requires a USB or RS-232 serial connection. TESTLINK PCE-330 SOFTWARE (1) The SE-318 package contains: ... - Page 11 Hygro-Thermometer 8. After finish installing USB-120 connector driver, it will install SE318 software automatically. it will copy SE318.exe ( executable file ) and help file to your hard disk ( default is c:\program files\SE318. 9. After finish installation, plug USB-120 connector to PC usb port, execute.
- Page 12 Hygro-Thermometer Sampling Rate - Time interval between each data to be recorded. If you want to change it, move mouse cursor to the digit you want to change and click, then input the new sampling rate. The change will be effective immediately. It will keep up to 5000 data points, when data points exceed this limit, the oldest 100 points will be replaced sequentially.
- Page 13 Hygro-Thermometer The Tabular window can be used to record real time data in a table format. The maximum number of records that the Tabular window can keep will be depending on how many available memory and hard disk space of the connected computer. (8) Data Logger When you have thermometer connected to computer, select "Load Data"...
-
Page 14: Maintenance
Hygro-Thermometer How to uninstall SE318? Uninstall SE318 by launching the Add/Remove Programs applet out of the Control Panel, highlighting the SE318, and clicking on the Add/Remove... button, then it will remove the SE318 folder and files from your computer. 10. MAINTENANCE In order to ensure the accuracy of the thermometer for a longer period of time you should calibrate it once a year. - Page 15 Hygro-Thermometer PCE Instruments...
