Extron electronics USB HUB4 Series User Manual page 21

Wall opening
flush with
edge of box
Extron
USB HUB4 MAAP
USB Hub
Figure 12. Installing a USB HUB4 MAAP in a One-gang Wall Box
Mounting the hub to a mounting bracket
1.
Mount the HUB4 to an AAP or MAAP mounting frame (see
mounting frame on page 12).
2. Attach all required cables to the rear panel ports of the HUB4 and test the system.
3. Attach the AAP or MAAP mounting frame with the attached HUB4 to the mounting
bracket using the two included mounting screws (see figure 13).
NOTE: Use an AAP or MAAP blank for any unused faceplate openings.
Extron
CPM101
Mounting Frame
Figure 13. Mounting a USB HUB4 MAAP to a Mounting Bracket
R
W E
P O
A P IT Y
TI V
M A
0 1 A C
T 0
V T
P
A A
4 M
U B
B H
U S
Extron
CPM101
Mounting Frame
Wall
Wall Mounting
Bracket
R
W E
P O
IT Y
A P
T IV
M A A C
0 1
T 0
V T
P
A A
4 M
U B
B H
U S
Extron
USB HUB4 MAAP
USB Hub
Mounting the hub to a
USB HUB4 Series • Mounting 13
