Charging mode

General informa- Charging mode is used for:
tion
-
-
Charging the
NOTE!
battery
Danger due to a faulty battery.
This can result in damage to property.
▶
1
4
NOTE!
Danger if the wrong battery voltage is set.
This can result in damage to property.
▶
Charging or conservation charging with the battery either fitted or removed
Charging while vehicle consumers are switched on
Before charging, ensure that the battery to be charged is fully functional.
Plug in charger mains plug
Use the Menu key to select the "Ah" or "Battery type"
2
setting.
Use the Up/Down keys to enter the required value (e.g.
3
100 Ah or "Wet" battery type).
Connect the battery, observing the correct polarity. Because the charging
terminals are de-energised, there is no risk of sparks when connecting to the
battery, even if the charger is already connected to the mains supply.
- Connect the red charging lead to the positive pole (+) of the battery
- Connect the black charging lead to the negative pole (-) of the battery
Always ensure that the correct battery voltage is set.
Charging mode is automatically star-
ted after the charger is connected to
the mains.
The charger automatically identifies
the battery, e.g. 12 V, and starts the
charging process after 5 seconds.
If the battery voltage is not correctly
identified (e.g. in the event of a deeply
discharged battery), you have 5
seconds to enter the correct battery
voltage, as follows:
