Pyronix Kudos DT Quick Start Manual page 2

COVERAGE PATTERN AND PLAN VIEW
A
A A1
A1 15m VOLUMETRIC LENS
90 O
74 zone edges
HORIZONTAL COVERAGE
7 planes
15m
14m
13m
12m
11m
10m
9m
8m
7m
6m
5m
4m
3m
2m
1m
1m 2m 10m 14m 15m
3m 4m 5m 6m 7m 8m 9m 11m 12m 13m
VERTICAL COVERAGE
2.4m
D
MOUNTING AND
CABLE ENTRY KNOCKOUTS
D3
D2
NOTE:
D1
D2 and D3 have
been designed to
allow the detector
to be mounted in
a corner,
45 degrees to
a wall or flat
against a wall.
F3 NORMALLY CLOSED OPERATION
NORMAL ALARM
A2
MICROWAVE COVERAGE PATTERN
15m
14m
13m
12m
11m
10m
9m
8m
7m
6m
5m
4m
3m
2m
1m
1m
2m 3m 4m 5m 6m 7m 8m 9m 10m 11m 12m 13m 14m 15m
Note:
The microwave coverage pattern will completely fill
the area that the detector is placed in.
Any area up to 15m X 15m
E
PIR DETECTION METHODS
SPP+ = Two opposing detection zones must be crossed.
SPP+1 = Two opposing detection zones and any
other zone must be crossed.
Switch
D
SPP+ ON
SPP+1 OFF
SPP+
SPP+1
REMOVING AND REPLACEMENT OF FRONT COVER AND LENSES.
G
G1
NOTE:
When removing the
front cover leave the
screw in place
B DIMENSIONS AND WEIGHT
Kg
79.2 g
155mm
55mm
65mm
F
0.3 - 3.0 m/s
G2
REMOVING THE LENS:
With the front cover removed,
unclip the lens as shown above.
C
BOARD LAYOUT
Optional
C3
rear tamper
C3
-
+ N C T T
ON = Normal, link fitted
OFF = Optional, rear tamper
spring fitted
Microwave
adjustment
Tamper Switch
Orange LED =
microwave
A
B
C
C2
D
WIRING TO CONTROL PANEL
TAMP
ZONE
9 - 16Vdc
35mA
12V
60V
@12Vdc
50mA
50mA
REPLACING THE LENS:
Locate the lens by hooking onto the three bottom pegs
and push the lens into position, ensuring that the lens
is secure via the side and top clips.
On Off
C2
Dip Switches
A
A = LED Disable
B
B = 50 / 60Hz
C
C = AND / OR
D
D = PIR Mode
Green LED = PIR
Red LED = Alarm
C1
PYRO
SENSOR
F2
T T
NORMAL
T T
TAMPER ALARM
