Chapter 1
Double Stack Back-Panel I/O Connectors with PC99 Colored Codes
- PS/2 Mini-DIN keyboard and mouse ports
- Two Channel USB ports
- One D-SUB 9-pin male serial port
- One D-SUB 15-pin VGA port
- One D-SUB 25-pin female Printer port
- One D-SUB 15-pin female Game/MIDI port
- Audio Line-out, Line-in, Mic-in jack
Embedded PCI Audio Subsystem
- CMedia 8738 audio chip w/ integrated CODEC legacy audio
- Programmable independent sample rate form 4KHz to 48KHz for record and
playback
- Full-duplex operation for simultaneous recording and playback
- DLS-based wavetable music synthesizer w/ maximum 32 simultaneous notes,
supports MS DirectMusic (Wavetable technology licensed from ERSO w/
General MIDI 128 sounds, 8 drum kit)
- 32-voice HRTF 3D positional audio, CRL 3D supports MS DirectSound3D,
Aureal A3D and Creative EAX(Environment Audio Extensions) APIs
- Optional supports 24-bit S/PDIF-in/out for digital audio
- Selection of 4 or 6-channel speaker audio support is easy to build up a Home
Theater environment
- Supports MIDI and dual game ports
- PCI V2.1 compliant and full Legacy DOS software compatible
- Supports Fiber Optic module for Internet music, PC, and MD connections
Embedded USB Controller
- USB host controller (UHCI v1.0 compliant) with Root Hub
- Four USB ports with over-current protection
- Optional USB riser with 2 additional USB ports
Embedded System Monitoring Hardware Subsystem
- 5 external voltage inputs for CPU Vcore, VDD, +12v, +5v and 3.3v (internal
detecting)
- 2 temperature sensor with thermistor for CPU and System
- 2 Fan speed (CPU and System) monitoring
 Board Dimensions
- Micro ATX form factor, 244mm x 220mm, 4 Layers
