Chapter 2
Onboard Audio (JP2)
Optional USB Device Power On Function (JP3)
Clear CMOS Data Jumper (JP5)
14
1
Enable (default)
This function allows you to enable and disable
the onboard audio. You must set the jumper's cap
to pins 1-2 to enable or set pins 2-3 to disable
this function.
Disable (default)
This mainboard is able to be turned on by a USB
keyboard hot key or a USB mouse click. You
must also set this jumper's cap to pins 2-3 to use
this function. The "OnChip USB and USB
Keyboard support" must be set to Enable (see
section 3-4).
Normal (default)
To clear the contents of the CMOS, please follow
the steps below.
1. Disconnect the system power supply from the
power source.
2. Set the jumper cap at location 2~3 for 5 seconds,
then set it back to the default position.
3. Connect the system's power and then start the
system.
4. Enter BIOS's CMOS Setup Utility and choose
Load Setup Defaults. Type Y and press enter.
5. Set the system configuration in the Standard
CMOS Setup menu.
Disable
Enable
Clear CMOS Data
