Summary of Contents for NetPing Uniping server solution v3/SMS
- Page 1 [ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide ...
-
Page 2: Table Of Contents
[USS] Copyright and Disclaimer ................. 6 [USS] A Device Overview..................... 7 Function of a Device........................... 7 Appearance of a UniPing server solution v3/SMS Device ..............7 Appearance of a UniPing server solution v3 Device ................. 8 [USS] Installing and Removing a SIM Card ..............9 Removing a SIM Card ......................... - Page 3 [USS] Setting Parameters to Default Values (to the Factory Settings)....30 [USS] Shipping Kit ..................... 31 Shipping kit of a UniPing server solution v3/SMS device............... 31 Shipping kit of a UniPing server solution v3 device ............... 32 [USS] Warranty ......................33 [USS] Operating and Storage Conditions ..............
- Page 4 [ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide - – ...
-
Page 5: [Uss] Introduction
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Introduction [USS] Introduction This user guide helps to become familiar with an operation of a Uniping server solution v3/SMS device and get an idea about its functionality and technical specifications as well as prepare a device for an operation. -
Page 6: [Uss] Copyright And Disclaimer
User Guide, as well as firmware and software of devices and this User Guide belong to NetPing global Ltd. Сopying, replication and translation of this user guide to other languages are not allowed without a prior written permission of a rightholder. -
Page 7: [Uss] A Device Overview
A device can be powered from an ordinary 220 V AC socket (internal battery) or from external power supply unit 5V DC (1,5A). Appearance of a UniPing server solution v3/SMS Device A device has a standard size to be mounted in a 19' rack. A height of a device is 1U. The appearance is shown below: Picture 1 –... -
Page 8: Appearance Of A Uniping Server Solution V3 Device
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] A Device Overview Appearance of a UniPing server solution v3 Device A device has a standard size to be mounted in a 19' rack. A height of a device is 1U. Appearance is shown below: Picture 3 –... -
Page 9: [Uss] Installing And Removing A Sim Card
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Installing and Removing a SIM Card [USS] Installing and Removing a SIM Card Information in the section applies to a UniPing server solution v3/SMS device with a built-in GSM modem. Install and remove a SIM card when a device is de-energized! Install a SIM card in the next way: With a slight touch of a finger, install a SIM card until it clicks:... -
Page 10: [Uss] Sockets And Indication Elements
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Sockets and Indication Elements [USS] Sockets and Indication Elements POWER LED A POWER LED (see picture 1 and picture 2), when turned on, means that the device works. IO Lines Connection Terminals Picture 1 – A terminal block for connecting IO lines... -
Page 11: Io State Leds
Voltage of the logic "0": <0,9V It is possible to plug relay coils to UniPing Server Solution v3/SMS IO lines directly. A voltage of triggering a relay should be either 12 V or 5 V, and a triggering current - no more than 200mA. Control relay contacts are connected to an IO terminal and to the terminal +12 V or 12 V relay or a +5 V terminal for a 5 V relay. -
Page 12: Smoke Terminals
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Sockets and Indication Elements Smoke Terminals Picture 5 – Terminals «Smoke» (UniPing server solution v4/SMS monitoring unit) Picture 6 – Terminals «Smoke» (UniPing server solution v3 monitoring unit) A SMOKE terminal block is used to plug in a smoke sensor. 1W Sockets ... -
Page 13: Rs232 / Rs485 Sockets
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Sockets and Indication Elements Picture 8 – «1W» sockets (UniPing server solution v3 monitoring unit) 1W sockets are used to plug in sensors of a model line 1-Wire, that are built using a 1Wire technology. To make sensors plug-in more convenient, there are four sockets on a body of a device. - Page 14 [ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Sockets and Indication Elements RS232/RS485 socket is used to plug in RS232/RS485 devices. A port RS232/RS485 can work in the mode of converting interfaces RS232/RS485 – Ethernet via TCP protocol. Important! Ports RS232 and RS485 use one bus inside a device.
-
Page 15: Relay Socket (Pwr)
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Sockets and Indication Elements Relay Socket (PWR) Picture 11 – Socket «Relay» (UniPing server solution v4/SMS monitoring unit) Picture 12 – Socket «PWR» (UniPing server solution v3 monitoring unit) Contacts of a relay, built into a body of a device, are output normally opened and normally closed. A relay can be used for managing a Reset button of a computer as well as for connecting an Alarm АС-10. -
Page 16: Lan Sockets
Ethernet 10/100 BASE-T ports form together a two-port Ethernet switch. One port is used to connect to a network, and the other one - to connect an additional equipment (another NetPing device, an administrator's laptop, etc.), which gives a possibility not to install an additional switch on a remote land. These ports are equal, and any of them can be used to connect to a network. ... -
Page 17: Gsm Sockets
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Sockets and Indication Elements GSM Sockets Picture 15 – GSM modem sockets (UniPing server solution v4/SMS monitoring unit) A GSM ANT socket is designed for plugging in an external antenna, which is included into a shipping kit. A SIM Card slot is designed for installing a SIM card. - Page 18 [ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Sockets and Indication Elements Picture 16 – 5V DC Input (UniPing server solution v4/SMS monitoring unit) Picture 17 – 5V DC Input (UniPing server solution v3 monitoring unit) Picture 18 – 220V AC Input (UniPing server solution v4/SMS monitoring unit) Picture 19 –...
-
Page 19: [Uss] Using Io Lines To Control External Devices (In The "Output" Mode)
MP701 a power module switch (4 independent channels, 2 kW 10A each) (check out the compatibility of this relay with the NetPing device model on the relay web page on the site); For more detailed information, please contact a technical support support@netpingdevice.com. -
Page 20: Equivalent Сircuit
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Using IO Lines to Control External Devices (in the «Output» Mode) Equivalent Сircuit [USS] Using IO Lines to Control External Devices (in the «Output» Mode) – ... -
Page 21: [Uss] Sensors Plugin
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Sensors Plugin [USS] Sensors Plugin It is prohibited to plug sensors and external modules into NetPing devices when a power supply is on! Configuring a device and receiving notifications from sensors are described in the document «Firmware... -
Page 22: H2O Leakage Sensor
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Sensors Plugin Sensor Flex UniPing server solution v4/SMS, UniPing server solution v3 Terminal Block First wire One of IO lines – 1 - 8 Second Wire Important! Sensors of a dry contact type, a supply voltage sensor, a leakage sensor, and others are plugged to IO lines of a device. -
Page 23: Supply Voltage Sensor
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Sensors Plugin Sensor Flex UniPing server solution v4/SMS, UniPing server solution v3 Terminal Block Green One of IO lines – 1 - 8 Yellow (White) Black Important! Sensors of a dry contact type, a supply voltage sensor, a leakage sensor, and others are plugged to IO lines of a device. -
Page 24: Shock Sensors
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Sensors Plugin UniPing server solution v4/SMS, UniPing server Sensor Flex solution v3 Terminal Block Red wire (labeled) +12V Second wire after a labeled one Third wire after a labeled one Fourth wire after a labeled one One of IO lines –... -
Page 25: Motion Sensors
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Sensors Plugin Important! Sensors of a dry contact type, a supply voltage sensor, a leakage sensor, and others are plugged to IO lines of a device. You can plug up to eight sensors of this set. Important! A correspondent IO line should be set to an input mode in settings of a device. -
Page 26: Smoke Detector (Mod. M206-5E)
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Sensors Plugin independently with the help of any wire with a minimum cross section of 0,4 mm . Maximum allowable length of a flat cable is 100 m. Smoke detector (mod. - Page 27 [ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Sensors Plugin Theoretically, a number of sensors in a circuit is not limited. The main requirement is to maintain a loop resistance in a standby mode at 3.3 kOhm (determined by a resistor at the end of a circuit). I.e. sensors can be added to a circuit until a loop resistance is not increased because of resistance of connecting wires.
-
Page 28: Netping Ac/Din External Sockets
RELAY "Off" there is voltage in a socket A relay with normally closed contacts is used for a load commutation in a NetPing AC/DIN. This means having 220 V on a socket and a voltage turned on when a control wire is not plugged in. -
Page 29: Electricity Meter "Energy Meter Ce102
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Sensors Plugin Electricity Meter "Energy Meter CE102" An electricity meter is connected by a two-wire line according to the table: Meter Socket UniPing server solution v4/SMS Terminal Block 11 (В) RS485- 12 (А) RS485+... -
Page 30: [Uss] Setting Parameters To Default Values (To The Factory Settings)
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Setting Parameters to Default Values (to the Factory Settings) [USS] Setting Parameters to Default Values (to the Factory Settings) Resetting parameters to the factory settings is necessary in the following cases : •... -
Page 31: [Uss] Shipping Kit
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Shipping Kit [USS] Shipping Kit Shipping kit of a UniPing server solution v3/SMS device A shipping kit includes: • UniPing server solution v3/SMS device – 1 pc.; •... -
Page 32: Shipping Kit Of A Uniping Server Solution V3 Device
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Shipping Kit Shipping kit of a UniPing server solution v3 device A shipping kit includes: • UniPing server solution v3 device – 1 pc.; • computer power cable 1,8 meters – 1 pc.; •... -
Page 33: [Uss] Warranty
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Warranty [USS] Warranty The manufacturer guarantees normal operation of the product within 24 months from the date specified on the warranty sticker if a buyer follows operating and storage conditions. Manufacturer warranty applies only to failure of a device which occurred because of defects in manufacturing process of products and components used. -
Page 34: [Uss] Operating And Storage Conditions
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Operating and Storage Conditions [USS] Operating and Storage Conditions A device is designed for continuous round the clock operation indoors. In operating conditions of use, a device is resistant to an environment with temperature in a range of 0°С... -
Page 35: [Uss] Safety Precautions
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Safety Precautions [USS] Safety Precautions The next information will allow users to avoid both injuries and damaging a device as well as connected equipment. • A device must be plugged to a power supply socket with a ground or a hole, where a contact is inserted. A contact must be located at a plug and be connected to a ground wire. -
Page 36: [Uss] Where To Get A Document Of A Firmware Description
Go to the page of a description of a necessary device: • UniPing server solution v3/SMS • UniPing server solution v3 Go to the section «Documentation and Files»: Go to the link «Firmware description DKSF 70.5 IU»: A version in the document «Firmware Description»... -
Page 37: [Uss] Additional Documents And Links
[ENG] UniPing server solution v4/SMS & UniPing server solution v3, User guide -[USS] Additional Documents and Links [USS] Additional Documents and Links Technical support for Netping devices Manufacturer's website: http://www.netpingdevice.com/ Kindly see our blog for articles with examples of using the devices and news on issuing new firmware versions.
