3 year guarantee - Made in France
MINI
GEMINI
(EN) Pulley
MINI
(FR) Poulie
(DE) Seilrolle
(IT) Carrucola
(ES) Polea
7
WARNING
Activities involving the use of this equipment are inherently dangerous.
You are responsible for your own actions and decisions.
Before using this equipment, you must:
- Read and understand all Instructions for Use.
- Get specific training in its proper use.
- Become acquainted with its capabilities and limitations.
- Understand and accept the risks involved.
Tracability and Markings
MINI
GEMINI
Traceability:
c.
datamatrix = product
reference +
individual number
Rope
d.
diameter
1
P59A Mini / P66A GeMini P595010A (220609)
GEMINI
80 g
135 g
11 mm
7
11 mm
FAILURE TO HEED ANY OF THESE
WARNINGS MAY RESULT IN SEVERE
INJURY OR DEATH.
Body
Notified body
a.
b.
controlling the
that carried
manufacture
out the CE type
of this PPE
inspection
TÜV Rheinland
APAVE SUD Europe
Product Safety
BP 193, 13322
GmbH Am Grauen
Marseille Cedex 16
N°0082
Stein
D-51105 KÖLN
N°0197
e.
Individual number
00 000 A 0000
Year of
f.
manufacture
Day of
g.
manufacture
Control or name
h.
of inspector
i.
Incrementation
NFPA
CERTIFICATION FOR
MINI P59A and
GEMINI P66A
THIS MINI / GEMINI MEETS THE
AUXILIARY EQUIPMENT REQUIREMENTS
OF NFPA 1983, STANDARD ON LIFE
SAFETY ROPE AND EQUIPMENT FOR
EMERGENCY SERVICES, 2006 EDITION.
MBS 23 kN
L (LIGHT USE)
MEETS NFPA
1983 (2006 ED.)
After removing the notice from the equipment,
make a copy of it and keep the original as part
of a permanent record that includes the usage
and inspection history for the equipment. Keep
the copy of the notice with the equipment and
refer to it before and after each use. Additional
information regarding auxiliary equipment can
be found in NFPA 1500, Standard on Fire
Department Occupational Safety and Health
Program, and NFPA 1983, Standard on Fire
Service Life Safety Rope and System
Components.
1.
Field of application
2.
Nomenclature of parts
MINI
1
2
3
Patented
4
GEMINI
1
2
3
Patented
4
3.
Inspection, points to verify
4.
Compatibility
MINI / GEMINI
x2
GEMINI

Advertisement

loading
Need help?

Need help?

Do you have a question about the MINI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Petzl MINI

  • Page 1 MINI / GEMINI Traceability: Patented datamatrix = product reference + individual number Individual number 00 000 A 0000 GEMINI GEMINI Year of manufacture Day of manufacture Control or name Patented of inspector Rope Incrementation diameter P59A Mini / P66A GeMini P595010A (220609)
  • Page 2 P = 100 kg P = 100 kg F = P F = 0,5 P Theoretical force F = 1,1 P F = 0,52 P F = 2 P F = 0,66 P P59A Mini / P66A GeMini P595010A (220609)
  • Page 3 F = 0,875 P Progress capture Positioning and redirection systems MINI / GEMINI 2 kN 1 kN 1,4 kN 90° 120° P = 100 kg P = 100 kg P = 100 kg P59A Mini / P66A GeMini P595010A (220609)
  • Page 4 (KR) 확보점 (ES) Anclaje (CZ) Ukotvení (CN) 确定点 (PT) Amarração (PL) Punkt (TH) สมอ (NL) Verankering stanowiskowy Latest version Other languages PETZL ISO 9001 ZI Cidex 105A Copyright Petzl 38920 Crolles France www.petzl.com/contact P59A Mini / P66A GeMini P595010A (220609)
  • Page 5 トレーサビリティ : データマトリクスコード = 製品番号 + 個 ンプをプーリーと組み合わせて使用する場合は、 システムの破 別番号 断荷重はロープクランプを通っているロープの強度によって d. 直径 決まります。 ペツル製の歯の付いたカムを持つロープクランプ e. 個別番号 の場合は4~6kNです (ロープによって変わります) 。 その他の f. 製造年 ロープクランプを使用する場合は、 その製品の取扱説明書を g. 製造日 参照下さい。 h. 検査担当 i. 識別番号 P59A Mini / P66A GeMini P595010A (220609)
