2-2 Product Specifications
Item
Capacity
Running Frequency
Dehumidifying
Performance Air Volume
Noise
Energy Efficiency
Ratio
Power
Power Consumtion
Power Operating Current
Power Factor
Outer Dimension
Weight (Net)
Refrigerant Pipe
Drain Hose
Size
Compressor
Oil Type
Blower
Heat Exchanger
Refrigerant Control Unit
Freezer Oil Capacity
Refrigerant to Change (R410A)
Protection Device (OLP)
Cooling Test Condition
Heating Test Condition
Operation conditon range
2-2
Model
Type
Cooling
kW
(Low / Std / Max)
Heating
Cooling
Hz
(Low / Std / Max)
Heating
ℓ/h
Cooling
㎥/min
(H/M/L)
Heating
Cooling
dB
(H/L)
Heating
Cooling
W/W
(Std)
Heating
ph-V-Hz
Cooling
W
(Low / Std / Max)
Heating
Cooling
A
(Low / Std / Max)
Heating
Cooling
%
(Low / Std / Max)
Heating
Width x Height
mm
x Depth
kg
Liquid mm x L(m)
Gas mm x L(m)
D x L(mm)
Type
Type
Motor
Rated Output
Type
Type
Motor
Rated
W
Output
cc
g
indoor
cooling
Outdoor
indoor
heating
Outdoor
AQV18V*A
Indoor Unit Outdoor Unit
Wall-mounted
1.60 / 5.00 / 6.00
1.50 / 6.00 / 8.00
20 / 68 / 85
20 / 75 / 100
1.56
12.33/11.40/10.57 47
13.88/12.91/11.97 46
48/33 58
48/33 58
3.21
3.41
1-220/240-50
500 / 1560 / 1950
450 / 1760 / 2600
2.4 / 7.0 / 9.0
2.3 / 8.0 / 12.0
75 / 90 /95
75 / 90 /95
1065 X 298 X 214 880 X 638 X 310
13.0 46.0
Φ6.35 x 5
Φ12.70 x 5
Rotary, G4B135LUAEH
Hermetic
1324W
FREOLα68ES-T
Cross-flow Propeller
Resin / Steel, AC Resin / Steel, DC
40 90
2 Row 16 Step 2 Row 28 Step
EEV
600
1,450
None
Indoor Unit : DB27°C WB 19°C
Indoor Unit : DB20°C WB 15°C
16°C ~ 32°C
-10°C ~ 43°C
27°C or less
-15°C ~ 24°C
AQV24V*A
Indoor Unit Outdoor Unit
Wall-mounted
2.20 / 6.80 / 8.00
1.90 / 8.00 / 10.00
15 / 54 / 68
15 / 59 / 85
2.81
14.24/12.47/10.65 47
14.81/12.99/12.05 46
48/33 60
48/33 60
3.01
2.81
1-220/240-50
590 / 2260 / 2950
560 / 2850 / 4000
3.0 / 10.6 / 13.9
2.8 / 13.0 / 19.0
75 / 90 /95
75 / 90 /95
1065 X 298 X 214 880 X 638 X 310
13.0 50.0
Φ6.35 x 5
Φ15.88 x 5
Rotary, G8T260FUAEW
Hermetic
2454W
FREOLα68ES-T
Cross-flow Propeller
Resin / Steel, AC Resin / Steel, DC
40 93
2 Row 16 Step 2 Row 28 Step
EEV
700
1,450
None
Outdoor Unit : DB35°C WB 24°C
Outdoor Unit : DB7°C WB 6°C
16°C ~ 32°C
-10°C ~ 43°C
27°C or less
-15°C ~ 24°C
