4. Mount the washer and shaft bolt
and finger tighten the bolt (Fig. 10).
5. Mount the "Blade Set" nuts and
finger tighten them with the "Blade
Set" bolts behind (Fig. 11).
6. Insert a manual screwdriver or
metal rod 5/16" (8 mm) or less in
the stabilizer hole. This is to stop the
blade from rotating while tightening
the bolt/nuts (Fig. 12).
7. Use a torque wrench with 9/16"
(14mm) socket to tighten shaft bolt
in CLOCKWISE direction to 36-43
ft-lb (50-60 N.m.) and alternate to
11/16" (17mm) socket to tighten
"Blade Set" nuts in CLOCKWISE
direction to 22 ft-lb (30 N.m.).
56-VOLT LITHIUM-ION CORDLESS LAWN MOWER — LM2130SP/LM2130SP-FC/LM2130/LM2130-FC/LM2150SP/LM2150SP-FC
10
Washer
Shaft Bolt
11
"Blade Set" Nuts Finger Tightened
12
