  • Page 2 Introducing the new APOLLO II Pro Electric RTR 1/8th scale off-road professional ready to run buggy from SWORKz. The 1/8th APOLLO II EP buggy is a Pro RTR based on the pro S350 but with an updated S35-4E buggy center layout.

  • Page 3: Specification

    Contact your local hobby shop or SWORKz distributor for all claims and questions. Claims must be well documented. All Claims are subject to expert...

  • Page 4: Assembly Steps

    I N D E X INSTRUCTION Warranty Required Equipment for Operation Operation Guide Assembly Steps 7-33 Apollo II EP Part No. List 34-35 Apollo II EP Spare Part No. List 36-37 Apollo II EP Option Part No. List 38-39 End cover This radio controlled racing car is not a toy! This high-performance R/C model is recommended for ages 14 and older.
  • Page 5 R e q u i re d Equ ip me nt fo r O p erat io n Radio Gear Stick Type Receiver ESC system Steering servo Wheel & Trigger Type Breshless Motor Charger and LiPo Battery Tools Recommended Long nose pliers Side cutter 1.5mm Paint...

  • Page 6: Thread Locking Compound

    The APOLLO Kit is not intended for children under the age of 14 without adult supervision. SWORKz shall not be held liable for any loss or damages, whether direct, indirect, act of nature, arising from the abuse or misuse of this product or any other product required while operating this model.
  • Page 7 Bevel Gear Shaft 101004 Washer 3.5X10X0.2mm 610002 101004 101004 320004 330013 101004 320004 101004 Fill the differentials with oil up to 70% above the satellite gears. Put the SWORKz Diff. Oil 4000cps for the front Diff. and 1500cps for the rear Diff.
  • Page 8 Bevel Gear Shaft 108007 610002 101004 Washer 3.5X10X0.2mm 2501469-01 (45T) 101004 2501469-02 (46T) 2501469-03 (47T) 108007 101004 320004 330013 320004 101004 101004 Fill the differentials with Oil up to 80% full. Use SWORKz Diff. Oil 6000cps for the center Diff.
  • Page 9 2501529 104010 M5x4mm Set Screw (Flat Bottom) 116006R 116006R 106010 M3x6mm Hex Socket OH/TP Screw 2501114 108001 M3x12mm FH/ST HEX Screw 106010 116006R Ball Bearing 8x16x5mm (Red Rubber Case) 2501114 330160 104010 101018 SHIM 13x16x0.2mm 108001 330227 2501096 108001 101018 2501114 108001 Please use the SHIM 13x16x0.2mm...
  • Page 10 104010 116006R M5x4mm Set Screw (Flat Bottom) 2501529 106006R 108001 M3x12mm FH/ST HEX Screw 2501114 106010 106008 330160 104010 M3x12mm Hex Socket OH/TP Screw 330830 116006R 330227 Ball Bearing 8x16x5mm (Red Rubber Case) 106008 101018 106008 108001 101018 SHIM 13x16x0.2mm Please use the SHIM 13x16x0.2mm to adjust when the play was bigger between the crown gear and pinion...
  • Page 11 2501100 108008 M3x35mm FH/ST HEX Screw 2501100 330831 2501099 101020A 3mm Countersunk Washers (GM) 330103 2501099 101020A 330103 108008 Use a 2mm Hex Wrench and slowly tighten the Hinge Pins. 2.0mm 330103 Front/Rear Lower Arm HingPin 200101 Pop in the Stabilizer Guide. 104004 After assembly ensure that both M3x3mm Set Screw...
  • Page 12 104005 M3x4mm Set Screw 105004 M2.6x6mm Cap Screw 104005 105004 104005 105004 106002 103001 106002 M3x10mm Hex Socket OH/TP Screw 2501099 103001 M3 Nut Lock 2501096E-1 106002 2501099 106002 300024 2501096 106002...
  • Page 13 106008 M3x12mm Hex Socket OH/TP Screw 330119 2501100 330119 2501113 Front Upper Arm HingPin 330828 330119 2501100 2501099 106008 2501113 330136 2501094C 2501121C 106005 M3x15mm Hex Socket OH/TP Screw 330134 106021A M4x10mm Hex Socket OH/TP Screw 106005 106021A...
  • Page 14 108005 330829 108005 M3x14mm FH/ST HEX Screw 2501122B 2501097 106002 M3x10mm Hex Socket OH/TP Screw 106008 M3x12mm Hex Socket OH/TP Screw 106002 106008 106008 The rear lower arm holder insert can offer 1.0, 2.0 and 3.0 rear kick-up for your rear lower suspension.
  • Page 15 Pop in the Stabilizer Guide. After assembly ensure that both 2501114 suspension arms move freely. 104004 M3x3mm Set Screw 104004 104004 105005 104005 M3x4mm Set Screw 105004 M2.6x6mm Cap Screw 104005 104005 105004...
  • Page 16 106007 106007 106004R 101021 330135A 103001 101021 M3 Nut Lock 338109 115004 101021 M3x8xT1mm 330251 101021 2501667 330251 106004R 101021 2501122B 2501122A 106007 M3x12mm Hex Socket OH/TP Screw(HT) 103001 116004R 103001 Ball Bearing 6x10x3mm (Red Rubber Case) 330114A 106002 106002 M3x10mm Hex Socket OH/TP Screw 116004R Ball Bearing 6x10x3mm (Red Rubber Case)
  • Page 17 106002 2501098A M3x10mm Hex Socket OH/TP Screw 106002 Right 340035 340035 330252 2501100 Left 330118A 2501098A 330118A Screw and adjust 330118A Knuckle 330252 Pivot Ball Nut so as the pivot ball can be moved smoothly. 2501100 104010 M5x4mm Set Screw (Flat Bottom) 330110 330111 Pin M2.5x14.8mm...
  • Page 18 104010 M5x4mm Set Screw (Flat Bottom) 330110 330111 Pin M2.5x14.8mm 330112 330109 330124 Pin M3.0x16.8mm 330111 116006R Ball Bearing 8x16x5mm (Red Rubber Case) 2501095A 2501095A 116006R 116012 330121A 116012 Right Ball Bearing 15x21x4mm 330124 Left 104010 330117A 330117A Knuckle Pivot Ball Washer 330117A...
  • Page 19 103001 2501100(3mm) 330401 Rear Hub Carriers Hing Pin with Nut 103001 330401 M3 Nut Lock 2501100(1mm) 2501121C 338070B 2501121C 330123A 330123A Rear Upper Sus. Arm Turnbuckles 330125 9.8mm...
  • Page 20 105011 M3x23mm Cap Screw 106002 M3x10mm Hex Socket OH/TP Screw 106002 103001 M3 Nut Lock 105011 103001 2501097 106008 2501097 103001 103001 106008 2501097 103001 106008 103001 2501097 M3 Nut Lock 106008 M3x12mm Hex Soket OH/TP Screw...
  • Page 21 106006 106003 M3x16mm Hex Socket OH/TP Screw 106006 M3x20mm Hex Soket OH/TP Screw 106003 108007 108007 228004A 108007 108007 108007 108007 108007 338108 M3x6mm FH/ST HEX Screw 108007 108007 108007 108007 228004A...
  • Page 22 108003 M3x10mm FH/ST HEX Screw 108010 M4x10mm FH/ST HEX Screw 108003 108010 108012 M4x16mm FH/ST HEX Screw 2501097B 108012...
  • Page 23 108012 M4x16mm FH/ST HEX Screw 108012 108012 106002 Motor is included. (SP-70105) 104011 340036 106002 106006 M3x10mm Hex Soket OH/TP Screw 228007 106008 106006 M3x20mm Hex Soket OH/TP Screw 330235 338107 106008 M3x12mm Hex Socket OH/TP Screw 105012 228007 106024 106024 M4x12mm Hex Socket OH/ST Screw 104011...
  • Page 24 330697 108003 M3x10mm FH/ST HEX Screw 330699B 108010 M4x10mm FH/ST HEX Screw 228007 108003 108010 338038B 338070B 228006-5 338070B 1.0mm 106002 M3x10mm Hex Soket OH/TP Screw 228006-5 338070B 104014 M5X25mm set screw 228006-5 104014 106002 106002 338070B 106002 106002...
  • Page 25 The 2503221BK Battery Stoper must be suit for different Lipo Battery style. 108006 M3x8mm FH/ST HEX Screw 108006 2503221BK 2503221BK 540001 2503221BK 540001 108006 108006 108006 M3x8mm FH/ST HEX Screw...
  • Page 26 Right 330777A 330813 Steering Turnbuckle 2501121C 2501121C 330813 Left 330777A 13.4mm 106002 M3x10mm Hex Soket OH/TP Screw 106002 106002...
  • Page 27 101012 330134 228006 108006 101012 M3x8mm FH/ST HEX Screw OPTION: SW-338078-25 108003 SWORKz Uni-Design 2-Way System Aluminum Steering Servo Horn 25T M3x10mm FH/ST SW-338078-23 SWORKz Uni-Design 2-Way System Aluminum Steering Servo Horn 23T 101012 M3x6xT0.6mm 228007 Servo is included. (SW-840023)
  • Page 28 ESC is included. (SP-70305) 108003 M3x10mm FH/ST 400013 400013 108003 108003 106010 200193 106010 M3x6mm Hex Socket OH/TP Screw 2503221 108007 M3x6mm FH/ST HEX Screw Receiver is included 108007 108007 2503221...
  • Page 29 103004 Front 330634 Front 330636 Rear 330633 330558(L) S350 New BBS System Shock Shaft (L) Rear 330635 400020 330559(S) 330562A S350 New BBS System Shock Shaft (S) 210058 101011 210058 210058 103004 M2.5mm Nut Lock 210058 330557 210058 Shock Seal Washer 3.5X7X1.0mm 2501121C 210058 Front 400010(S)
  • Page 30 330138 101010A 330138 105013A 101010A M3x25mm Cap Screw 101010A 105013A 101010A 105013A 103003A 103003 Flange M3 Nut Lock 103003A 106005 M3x15mm Hex Socket OH/TP Screw 106005 106005 103003A 103003A 106005 106005...
  • Page 31 105005 2501116 2501116 105005 M3x12mm Cap Screw 2501116 330122A Wheel Nut TPRO 3307-R2 Tires are included. 330122A 330122A...
  • Page 32 Lipo Batteries are not included Take off thin plastic protective layer from outside of the body shell, then put on the window and logo stickers. 250041RE-RD 510111 S350 Falcon Style 2 Sport Color Body Shell Window Decal...
  • Page 33 106010 M3x6mm Hex Socket OH/TP Screw Please drill a new hole between the old mark. 250041RE-RD 115019 106010 115019 250041RE-RD...
  • Page 34 Pa r ts No. L i s t Part No. Part Name Q`ty in Use ltem No. Part No. Part Name Q`ty in Use ltem No. 228004A S35-4 Series Plastic Side Guard Set with Stopper 1 SW-228004A Throttle Servo Horn (For Hitec) 210002B S35/S350 Series Big Bore Diff Case 3 SW-210002B...
  • Page 35 SHIM 6.0x10.0x0.2mm 1 SW-101019 101020A S350 Sries 3mm Countersunk Washers (GM) 2 SW-101020A 101021 M3x8xT0.8mm 4 SW-101021 101026 SWORKz Aluminum Washer 3X6X1.5mm 1 SW-101026 103001 M3 Nut Lock 11 SW-103001 103003A Flange M3 Nut Lock (GM) 4 SW-103003A 103004 M2.5mm Nut Lock...
  • Page 36 S350 Gear Box Set (F&R) SW-330831 S350 Sport Buggy Series Aluminum Front Lower Arm Plate SW-2501116 SWORKz High Done Force Wing Set (BK)(Fit S350) SW-338038B ZEUS 2.0/Apollo 2.0 Series Roll Bar Brace SW-2501121C S350/S350T Ball End Set with Shock Plastic Parts SW-338070B S35 Series Rear Upper Sus.
  • Page 37 Ball Bearing 5x10x4mm (Red Rubber Case)(4PC) SW-116012 Ball Bearing 15x21x4mm SW-800003 Switch SW-840023 SWORKz SES-2S 12kg Metal Gear Servo (F Connect) (Made by Savox) SW-840026 SWORkz SW-T2/R2 2.4G 3 channels Radio Set SP-80111 Spower Sport RTR .21 In-Line U Manifold SP-80112...
  • Page 38 O p ti on P a r t Lis t Item No. Part Name Item No. Part Name SW-228008BK SWORKz 1/8 Off Road Formula 2.0 Race Wing (BK) SW-338078-25 SWORKz Uni-Design 2-Way System Aluminum Steering Servo Horn 25T SW-228008WH SWORKz 1/8 Off Road Formula 2.0 Race Wing (WH)
  • Page 39 SW-360005 S35 Series Front Lower Arm Plate Balance Weight (25g) SWC-338102 S35 Series Pro-Titanium Pivot Ball Turnbuckle (2PC) SWC-338103 SWORKz 1/8 Series Pro-Titanium Linkage Turnbuckle (M5x35mm)(2PC) SWC-338104 SWORKz 1/8 Series Pro-Titanium Linkage Turnbuckle (M4x40mm)(2PC) SWC-338105 SWORKz Pro-Titanium Linkage Turnbuckle (M3x30mm)(2PC)
