  • Page 2 Introducing the new APOLLO II Pro Nitro RTR 1/8th scale off-road professional ready to run buggy from SWORKz. The 1/8th APOLLO II Nitro buggy is a Pro RTR based on the pro S350 but with an updated S35-3 buggy center layout.

  • Page 3: Specification

    Weight: 3400g WAR RAN TY Your SWORKz APOLLO II Nitro Pro RTR kit warranty covers workmanship and manufacturing defects of the original and unmodified parts. Warranty claims resulting from crashes, abuse, improper operation, improper mounting, improper adjustment or lack of maintenance will not be honored.

  • Page 4: Required Equipment For Operation

    I N D E X INTRODUCTION Warranty INDEX Required Equipment for Operation Operation Guide Assembly Steps 7-38 APOLLO II NITRO Key No. List 39-40 APOLLO II NITRO Spare Part List 41-42 APOLLO II NITRO Option Part List 42-43 End cover This radio controlled racing car is not a toy! This high-performance R/C model is recommended for ages 14 and older.
  • Page 5 R e q u i re d Equ ip me nt fo r O p erat io n Radio Gear Nitro fuel Receiver batteries Stick Type We recommend that you use fuel containg 20~25% nitro. Throttle servo On/Off Switch Receiver Wheel &...

  • Page 6: Thread Locking Compound

    The SWORKz APOLLO II Nitro Pro RTR is not intended for children under the age of 14 without adult supervision. SWORKz shall not be held liable for any loss or damages, whether direct, indirect, act of nature, arising from the abuse or misuse of this product or any other product required while operating this model.
  • Page 7 Bevel Gear Shaft 101004 Washer 3.5X10X0.2mm 610002A 101004 101004 320004 330013 101004 320004 101004 Fill the differentials with oil up to 80% above the satellite gears. Put the SWORKz Diff. Oil 4000cps for the front Diff. and 1500cps for the rear Diff.
  • Page 8 M3x12mm FH/ST HEX Screw 330013 Bevel Gear Shaft 101004 610020 Washer 3.5X10X0.2mm 101004 101004 320003 330013 320003 101004 Fill the differentials with oil up to 101004 above the satellite gears. Put the SWORKz Diff. Oil 6000cps for the center Diff.
  • Page 9 2501529 104010 M5x4mm Set Screw (Flat Bottom) 116006R 116006R 106010 M3x6mm Hex Socket OH/TP Screw 2501114 108001 M3x12mm FH/ST HEX Screw 106010 116006R Ball Bearing 8x16x5mm (Red Rubber Case) 2501114 330160 104010 101018 SHIM 13x16x0.2mm 108001 330227 2501096 108001 101018 2501114 108001 Please use the SHIM 13x16x0.2mm...
  • Page 10 104010 116006R M5x4mm Set Screw (Flat Bottom) 2501529 106006R 108001 M3x12mm FH/ST HEX Screw 2501114 106010 106008 330160 104010 M3x12mm Hex Socket OH/TP Screw 330830 116006R 330227 Ball Bearing 8x16x5mm (Red Rubber Case) 106008 101018 106008 108001 101018 SHIM 13x16x0.2mm Please use the SHIM 13x16x0.2mm to adjust when the play was bigger between the crown gear and pinion...
  • Page 11 2501100 108008 M3x35mm FH/ST HEX Screw 2501100 330831 2501099 101020A 3mm Countersunk Washers (GM) 330103 102020A 2501099 330103 108008 Use a 2mm Hex Wrench and slowly tighten the Hinge Pins. 2.0mm 330103 Front/Rear Lower Arm HingPin 2501114 Pop in the Stabilizer Guide. 104004 After assembly ensure that both M3x3mm Set Screw...
  • Page 12 104005 M3x4mm Set Screw 105004 M2.6x6mm Cap Screw 104005 105004 104005 105004 106002 103001 106002 M3x10mm Hex Socket OH/TP Screw 2501099 103001 M3 Nut Lock 2501096 106002 2501099 106002 338110 2501096 106002...
  • Page 13 106008 M3x12mm Hex Socket OH/TP Screw 330119 2501100 330119 2501113 Front Upper Arm HingPin 330828 330119 2501100 2501099 106008 2501113 330136 2501094C 2501121C 106005 M3x15mm Hex Socket OH/TP Screw 330134 106021A M4x10mm Hex Socket OH/TP Screw 106005 106021A...
  • Page 14 108005 330829 106008 M3x12mm Hex Socket OH/TP Screw 2501122A 2501097 108005 M3x14mm FH/ST HEX Screw 106002 M3x10mm Hex Socket OH/TP Screw 106002 106008 106008 The rear lower arm holder insert can offer 1.0, 2.0 and 3.0 rear kick-up for your rear lower suspension.
  • Page 15 Pop in the Stabilizer Guide. After assembly ensure that both 2501114 suspension arms move freely. 104004 M3x3mm Set Screw 104004 104004 105005 104005 M3x4mm Set Screw 105004 M2.6x6mm Cap Screw 104005 104005 105004...
  • Page 16 106007 106007 106004R 101021 330135A 101021 338109 115004 330251 101021 2501667-5 330251 103001 M3 Nut Lock 106004R 101021 2501122B 101021 M3x8xT1mm 2501122B 103001 106007 M3x12mm Hex Socket OH/TP Screw(HT) 103001 330114A 116004R Ball Bearing 6x10x3mm (Red Rubber Case) 106002 106002 M3x10mm Hex Socket OH/TP Screw 116004R Ball Bearing 6x10x3mm (Red Rubber Case)
  • Page 17 2501098A 106002 106002 Right M3x10mm Hex Socket OH/TP Screw 340035 340035 330252 2501100 Left 330118A 2501098A 330118A Screw and adjust 330118A Knuckle 330252 Pivot Ball Nut so as the pivot ball can be moved smoothly. 2501100 104010 M5x4mm Set Screw (Flat Bottom) 330110 330111 Pin M2.5x14.8mm...
  • Page 18 104010 M5x4mm Set Screw (Flat Bottom) 330110 330111 Pin M2.5x14.8mm 330112 330109 330124 Pin M3.0x16.8mm 330111 116006R 2501095A 2501095A Ball Bearing 8x16x5mm (Red Rubber Case) 116006R 116012 330121A Right 330124 Left 116012 Ball Bearing 15x21x4mm 104010 330117A Knuckle Pivot Ball Washer 330117A 330117A...
  • Page 19 2501100 103001 2501100 330401 103001 330401 Rear Hub Carriers Hing Pin with Nut 103001 M3 Nut Lock 330401 2501100 2501100 2501121C 330123A Rear Upper Sus. Arm Turnbuckles 330125 330123A 2501121C 330125 9.8mm...
  • Page 20 103001 M3 Nut Lock 105011 M3x23mm Cap Screw 106003 106003 M3x16mm Hex Socket OH/TP Screw 103001 105011 103001 2501097 106008 2501097 103001 103001 106008 2501097 103001 106008 103001 2501097 M3 Nut Lock 106008 M3x12mm Hex Soket OH/TP Screw...
  • Page 21 106006 106006 M3x20mm Hex Soket OH/TP Screw 106003 M3x16mm Hex Socket OH/TP Screw 106003 108007 108007 M3x6mm FH/ST HEX Screw 228004A 338111 108007 108007 108007 108007 228004A...
  • Page 22 106002 106002 M3x10mm Hex Soket OH/TP Screw 108003 M3x10mm FH/ST HEX Screw 108010 M4x10mm FH/ST HEX Screw 2501529 108012 M4x16mm FH/ST HEX Screw 108012 108003 108010 108003 108012 M4x16mm FH/ST HEX Screw 2501097B 108012 108012...
  • Page 23 106006 108012 M4x16mm FH/ST HEX Screw 108003 103001 M3x10mm FH/ST HEX Screw 2501529 106006 M3x20mm Hex Socket OH/TP Screw 103001 M3 Nut Lock 108012 108012 108003 104004 330104 106007 M3x12mm Hex Socket OH/TP Screw(HT) 108006 104004 M3x3mm Set Screw 108006 340038 108006 M3x8mm FH/ST HEX Screw...
  • Page 24 106009 106009 106009 106009 M3x25mm Hex Socket OH/TP Screw 300017 300017 2501124 2501124 330663A 330767A 108011 108011 M4x12mm FH/ST HEX Screw...
  • Page 25 Right 330777A 330813 Steering Turnbuckle 2501121C 2501121C 330813 Left 330777A 13.4mm 106008 M3x12mm Hex Soket OH/TP Screw 106008 106008...
  • Page 26 106001 106001 106003 106003 106001 M3x8mm Hex Socket OH/TP Screw 106005 M3x15mm Hex Soket OH/TP Screw 840023 840023 2503262 2503262 2503262 840025 800003...
  • Page 27 108006 108006 108006 M3x8mm FH/ST HEX Screw 104004 M3x3mm Set Screw Li-ion Size:18500 106001 M3x8mm Hex Socket OH/TP Screw 106001 106001 Battery is not included in the kit. 106001 200193 Li-ion Size:18650 104004...
  • Page 28 108006 M3x8mm FH/ST HEX Screw 108006 108006 108006 106007 106007 2501122B 330134 M3x12mm Hex Socket OH/TP Screw(HT) 103001 2501121C M3 Nut Lock 330155 Steering Servo Turnbuckle (M3x30mm) 330134 103001 330155 2501121C 17.2mm...
  • Page 29 106007 M3x12mm Hex Socket OH/TP Screw(HT) 106007 108006 108006 M3x8mm FH/ST HEX Screw 103001 M3 Nut Lock 103001 2501115 210033B 108006 M3x8mm FH/ST HEX Screw 106002 M3x10mm Hex Socket OH/TP Screw 106020 108006 M2.5x5mm Hex Socket OH/TP Screw 108006 106020 2501115 106002 106002...
  • Page 30 108003 M3x10mm FH/ST HEX Screw 108003 108003 105019 105019 101013 105019 M3x14mm Cap Screw 101013 101013 3mm Spring Washer 330008A 338037 338037 330229A 330229A...
  • Page 31 105001 M3x8mm Cap Screw 115048A 710007A 101021 M3x8xT0.8mm 330137 710007A 116010 116010 101015 M5x8xT0.4mm 101021 105001 115048A 116010 101015 101015 710007A Ball Bearing 5x10x4mm 115048A 105007A M4x8mm I-Head Screw 105007A 104011 M4x4mm Set Screw (Flat Bottom) SP-80111 108013 104011 M4x8mm FH/ST HEX Screw 330140A 330140A SP-80112...
  • Page 32 106007 210018 2503260 104004 104004 106020 104004 210018 330157A M3x3mm Set Screw 106020 2501125C 330156A 104004 210018 106007 2501112B M3x12mm Hex Socket OH/TP Screw(HT) 104004 2503260 330156A 210018 Throttle Rod 50mm 2501112B 210018 330157A 210018 2503260 Throttle Rod 60mm 330157 Brake Adjuster Knob 104004 106020...
  • Page 33 103004 Front 330634 Front 330636 Rear 330633 330558(L) S350 New BBS System Shock Shaft (L) Rear 330635 400020 330559(S) 330562A S350 New BBS System Shock Shaft (S) 210058 101011 210058 210058 103004 M2.5mm Nut Lock 210058 330557 210058 Shock Seal Washer 3.5X7X1.0mm 2501121C 210058 Front 400010(S)
  • Page 34 330138 101010A 330138 105013A M3x25mm Cap Screw 101010A 101010A 105013A 101010A 105013A 103003A 103003 Flange M3 Nut Lock 106005 103003A M3x15mm Hex Socket OH/TP Screw 106005 106005 103003A 103003A 106005 106005...
  • Page 35 Using air filter oil (included) 108006 610025 2501126A M3x8mm FH/ST HEX Screw 610025 2501126A 108006 2501126A...
  • Page 36 105005 105005 2501116 M3x12mm Cap Screw 2501116 2501116 330122A Wheel Nut 330122A 330122A...
  • Page 37 Take off thin plastic protective layer from outside of the body shell, then put on the window and logo stickers. 510111...
  • Page 38 106010 M3x6mm Hex Socket OH/TP Screw 115019 250041RN-RD 115019 106010 250041RN-RD...
  • Page 39 Pivot Ball Cup 8 SW-2501100 330006 Tornado Clutch Shoes 3 SW-330006 Lower Arm Insert (1mm) 330008A SWORKz Tornado Fly Wheel Set (GM) 1 SW-330008A Lower Arm Insert (1mm) 330008A Tornado Fly Wheel Center Nut 1 SW-330008A Rear Wheel Axle Insert (1mm)
  • Page 40 Diff. Gasket (0.5T) 3 SW-610002 610020 S35-3 Series Center Big Bore Plastic Diff. Case Gasket 1 SW-610020 610025 SWORKz 1/8 Nitro Buggy High Density Air Filter Foam Set 1 SW-610025 710007A 1/8 Sport Aluminum Clutch Shoes 3 SW-710007A 840023 SWORKz SES-2S 12kg Metal Gear Servo (F Connect)(Made by Savox) 2 SW-840023 840025 SWORKz SW-R2 2.4G 3 channels Reveiver 1 SW-840025...
  • Page 41 F/R Drive Shaft 93.5mm SW-610020 S35-3 Series Center Big Bore Plastic Diff. Case Gasket (3pc) SW-330110 CVD Join SW-610025 SWORKz 1/8 Nitro Buggy High Density Air Filter Foam Set (12 Sets) SW-330111 Pin M2.5x14.8mm SW-710007A 1/8 Nitro Buggy Aluminum Clutch Shoes (3PC) SW-330112...
  • Page 42 S350 Series Competition LDS 43T straight crown gear SW-210046 S350 Series LDS Universal Cross Drive Shaft Set 92.5mm (1pc) SW-250050 SWORKz 1/8 Off Road Formula Bulkhead Wing (4PC)/ Front Upper Arm's Wing Set (4PC) SW-250050A SWORKz 1/8 Off Road Formula Bulkhead Lexan Wing (0.8mm)(4PC) SW-330663...
  • Page 43 S350 Series Competition LDS 43T straight crown gear SW-210046 S350 Series LDS Universal Cross Drive Shaft Set 92.5mm (1pc) SW-250050 SWORKz 1/8 Off Road Formula Bulkhead Wing (4PC)/ Front Upper Arm's Wing Set (4PC) SW-250050A SWORKz 1/8 Off Road Formula Bulkhead Lexan Wing (0.8mm)(4PC) SW-330663...
