3.4.5

Electric system (direct-on-line starting)

The electric system is set for star-delta starting. The electric system consists of:
• a main power switch;
• a thermal relay for the protection of the electric motor;
a "forward running" contactor;
•
• a "reverse running" contactor.
The contactors are activated by a P.C. board, which checks the motor absorption through a current
transformer, and their size suits the absorption indicated on the motor rating plate.
CAUTION
The shredder user has to protect the mains to the electric switchboard by means
of fuses suitable to feed three-phases electric motors, rated as reported in the
electric component list, enclosed in the present manual.
