Summary of Contents for Intimus H200 CP4
- Page 1 H200 CP4 200 CP5 000524 H200 CP4 200 CP5 Betriebsanleitung Operating instructions Instructions d’opération Instrucciones de uso...
-
Page 2: Table Of Contents
200 CP5 / H200 CP4 Contents Maintenance/Disposing . . . . . . . . . 13 Safety Notes . . . . . . . . . . . . . . . . . . . . . 9 Cleaning the photocells ... -
Page 3: Initiation
(e.g. destruction of the cutting system). fig. 1 Assembly of the hopper extension Der Datenshredder intimus 200CP5/H200CP4 shred- der is used in all areas where large quantities of prin- 2 .4 Power supply connection ted material need to be shredded. -
Page 4: Operation
200 CP5 / H200 CP4 Operation = Pilot lamp a) „ready“ 3 .1 Operating functions Continously lights when the mains switch (fig. 2) is operated. b) „motor protection“ Flashes when the motor is overloaded. The machine cannot be started during the cooling down phase of the motor. -
Page 5: Operating The Machine
Translation of the Original Operation Manual Übersetzung der Originalbetriebsanleitung 3 .2 Operating the machine Feeding smooth paper: 1 . Feed smooth paper through the opening at CAUTION! the lower part of the hopper (Modell H200CP4) or through the opening of the hopper (Modell Risk of injury! 200CP5) to the cutting system. -
Page 6: Maintenance/Disposing
200 CP5 / H200 CP4 Malfunction NOTE! The machine will only run with closed door! 5 .1 Taking out excess paper in case of overload If the shredder has stopped due to an overload (motor Maintenance/Disposing protection) take the excess paper out of the inlet as follows: 4 .1 Cleaning the photocells... -
Page 7: Technical Data
Translation of the Original Operation Manual Übersetzung der Originalbetriebsanleitung Technical data Cutting size 200 CP5: 1,9x15 mm (Cross-Cut) H200 CP4 3,8x40 mm (Cross-Cut) Cutting capacity (in two stacks) 35-40 sheet (70g/m 2) 200 CP5: 70-80 sheet (70g/m 2 ) H200 CP4... -
Page 8: Certificate Of Conformity
200 CP5 / H200 CP4 Certificate of conformity 82810 18 07/21... - Page 9 Room 260D, C Building info@intimus.com.cn Guojigang No.E-2 Dong San Huan Bei Road, Chaoyang District, Beijing 100027, PRC Austria intimus International Austria Ges. m. b. H. + 43 (0)1 2583621 0 Leonard-Bernstein-Straße 10 contact.at@intimus.com 1220 Wien Belgium...
