CCR2216-1G-12XS-2XQ
CCR2216-1G-12XS-2XQ

Safety Warnings

Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents.
Ultimate disposal of this product should be handled according to all national laws and regulations.
The Installation of the equipment must comply with local and national electrical codes.
This unit is intended to be installed in the rackmount. Please read the mounting instructions carefully before beginning installation. Failure to use the
correct hardware or to follow the correct procedures could result in a hazardous situation for people and damage to the system.
Read the installation instructions before connecting the system to the power source.
It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling
requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik devices must be professionally installed.

First Use

Connect the device to the power source.
Use a Web browser or WinBox to connect to the default IP address of 192.168.88.1 from the first port, with the username
If IP is not available, download WinBox from our webpage and use it to connect through MAC address.
Update RouterOS software to the latest version, and make sure that the device has an internet connection.
If the device does not have an internet connection update software by downloading the latest version from our
/download
Find the latest software and choose your packages.
To get the architecture type of your device model, open WinBox or WebFig and see (System/Resources).
Download packages to the PC and upload them to the WinBox, WebFig, (Files) menu, and reboot the device.
Set up your password to secure the device.

Powering

The device accepts powering from two redundant power supplies, each accepts 100-240 V AC power. You can use either, or both at the same time. Up to
128 W power consumption.

Extension Slots and Ports

Product code CCR2216-1G-12XS-2XQ
CPU AL73400 2 GHz
CPU architecture ARM 64bit
CPU core count 16
Size of RAM 16 GB
RAM type DDR4
Storage 128 MB, NAND
Number of 1G Ethernet ports 1
Number of 25G SFP28 ports 12
Number of 100G QSFP28 ports 2
Number of M.2 SATA slots 2
  admin
 and no password.
webpage https://mikrotik.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CCR2216-1G-12XS-2XQ and is the answer not in the manual?

Questions and answers

Summary of Contents for MikroTik CCR2216-1G-12XS-2XQ

  • Page 1 Read the installation instructions before connecting the system to the power source. It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik devices must be professionally installed. First Use Connect the device to the power source.
  • Page 2 Operating system RouterOS (License level 6) Switch chip model 98DX8525 Switch connection to CPU 4x25 Gbps Dimensions 443 x 367 x 44 mm Operating temperature -20°C to +60°C * 100G QSFP28 supported speeds: 1x 100G; 1x 40G; 4x 25G; 4x 10G; 4x 1G. Not supported: 2x 50G; 1x 50G, 2x 40G * 25G SFP28 supported speeds: 1x 25G;...
  • Page 3 LEDs The device has four LED lights. PWR1/2 indicates which power supply is being used. FAULT indicates a problem with the cooling fans. USER can be configured using the software. Accessories EU/US power cord; Rack Mount bracket Back Side R0; Rackmount Case x72 Side Bracket;...
  • Page 4  support@mikrotik.com . Сделано в Китае, Латвии или Литве. Cм. на упаковке. Для получения подробных сведений о гарантийном обслуживании обратитесь к продавцу. Информация об импортерах продукции MikroTik в Российскую Федерацию: https://mikrotik.com/buy/europe/russia Продукты MikroTik, которые поставляются в Евразийский таможенный союз, оцениваются с учетом соответствующих требований...
  • Page 5 Information contained here is subject to change. Please visit the product page on   www.mikrotik.com   for the most up to date version of this document.
