Operation options
•  key and  key (ESC function - press keys simultaneously)
• In the menu, submenu: Pressing the key briefly:
• Exits the current menu level and takes you to the next higher level.
• If help text is open, closes the help text of the parameter.
• Pressing the key for 2 s returns you to the measured value display ("home position").
• In a text and numeric editor: Closes the text or numeric editor without applying changes.
•  key and  key (press keys simultaneously)
Reduces the contrast (brighter setting).
•  key and  key (press and hold keys simultaneously)
Increases the contrast (darker setting).
7.2 Access to the operating menu via the local display
Parameter/submenu
1)
Language
Setup
Setup→Mapping
Setup→Advanced setup
Diagnostics
2)
Expert
1) If you are operating via operating tools (e.g. FieldCare), the Language parameter is located under
"Setup→Advanced setup→Display"
2) When you call up the "Expert" menu, you are always asked for an access code. If a customer-specific access code
has not been defined, "0000" must be entered.
7.2.1 Opening the context menu
Using the context menu, the user can call up the following menus quickly and directly from
the operational display:
22
Meaning
Defines the operating language of the
local display
Once values have been set for the setup
parameters, the measurement should
generally be completely configured.
Mapping of interference echos
Contains additional submenus and
parameters
• For more customized configuration of
the measurement (adaptation to
special measuring conditions)
• For converting the measured value
(scaling, linearization).
• For scaling the output signal.
Contains the most important parameters
for diagnosing the condition of the device
Contains all the parameters of the device
(including those that are already
contained in one of the other menus).
This menu is organized according to the
function blocks of the device.
Levelflex FMP50 FOUNDATION Fieldbus
Description
BA01051F
GP01015F
