The abnormal conditions that can be displayed are listed below:
HIGH DC SHUTDOWN / SHORT CIRCUIT! / FUSE/OVERHEAT /
OVERLOAD SHUTDOWN / EMERGENCY STOP / INVERTER ABNORMAL /
BYPASS ON SHUTDOWN
Also, in the top right corner the screen, the UPS run time is displayed in year/month
for the reference of the user or maintenance personnel. This can be used to estimate
recurring maintenance intervals.
The screen will go back to MENU 1- SELECT MENU by pressing the ENTER (←
┘) key.
5.6. Menu 5 – Parameter Setting Menu
→ I N V E R T E R = O N / O F F
B U Z Z E R = O N / O F F
B O O S T C H A R G E
This menu is displayed when < PARAMETER SET > is selected from MENU 1,
and the correct password has been entered. The cursor (→) is used to select the
parameter the user wants to set, e.g., INVERTER ON/OFF, BUZZER ON/OFF,
BOOST CHARGE, DATE/TIME etc. The cursor (→) can be moved upward by the
UP (↑) key, and can be moved downward by the DOWN (↓) key. The selection is
confirmed by pressing the ENTER (←┘) key.
The first item that can be set is the INVERTER ON/OFF. When this is selected,
"INVERTER ON/OFF" will be displayed, where the "ON" will blink if the inverter
status is on, and the "OFF" will blink if the inverter status is off. The intended
status can be changed by UP (↑) or DOWN (↓) key, and is confirmed by ENTER
(←┘) key. Then "INVERTER = ON" will be displayed if "ON" is selected or
"INVERTER = OFF" will be displayed if "OFF" is selected, the UPS will switch
the inverter on or off according to the selection.
＜
P A R A M E T E R S E T T I N G
D A T E / T I M E
5-6
＞
E X I T
