1) Inspect and clean connecting
surfaces prior to lubrication and
assembly.
2) Use lubricants sparingly during
assembly; a light film is a all that
is required.
3) Use a small brush or cotton swab
to apply grease directly to O-rings
where they are not accessible (QC
fitting, M22 fitting).
6. CONNECT HOSE AND
WATER SUPPLY TO PUMP
IMPORTANT! DO NOT run the pump without
the water supply connected and turned on.
• Damage to pressure washer resulting from failure
to follow this instruction will void warranty.
NOTICE: Remove and discard the shipping caps
from the pump's high pressure outlet and water
inlet before attaching hoses.
1) Uncoil high pressure hose when handle folded,
and attach one end of hose to the base of the
spray gun. Tighten by hand. The other end already
assembled to the pump at the factory.
NOTICE: The hose only can be uncoiled from
the bottom of the hose reel, it's recommended to
keep the handle folded for easy unwinding and
winding the hose.
WARNING! The high pressure stream of water that the pressure washer
produces could cut through skin and its underlying tissues, resulting in serious
injury and possible amputation.
• NEVER connect high pressure hose to spray wand.
• Keep high pressure hose connected to pump and spray gun while system is
pressurized.
• Always be certain spray gun, wand, nozzles and other accessories are correctly
attached.
2) Before you connect your garden hose to the water inlet, inspect the inlet screen.
Clean the screen if it contains debris or have it replaced if damaged. Do Not run the
pressure washer if the inlet screen is damaged or missing.
15
209CC PRESSURE WASHER, 3200 PSI
OWNER'S MANUAL
E
F
C
D
