- Page 1 ELECTRIC PRESSURE WASHER 2300 PSI 3 Year Limited Warranty READ ALL INSTRUCTIONS BEFORE FIRST USE. KEEP THIS MANUAL FOR FUTURE REFERENCE. KEEP AWAY FROM CHILDREN. WEAR CSA APPROVED WEAR EAR WEAR A EYE PROTECTION PROTECTION FACE MASK...
-
Page 2: Product Specifications
PRODUCT SPECIFICATIONS ELECTRIC POWER WASHER Model 5044-036 Rated voltage AC 120V Rated frequency 60 Hz Rated current Rated pressure 1900 psi Maximum pressure 2300 psi Maximum water inlet pressure 170 psi Maximum water inlet temperature 122°F / 50°C Rated flow 1.3 GPM... -
Page 3: Table Of Contents
5044-036 ELECTRIC PRESSURE WASHER 2300 PSI TABLE OF CONTENTS Product Specifications .................. 1 Table of Contents ..................2 General Safety Instructions ................ 3-7 Unpacking ....................8 Preparation before Operation ..............9-10 Operation ....................10-13 Maintenance ..................13-14 Troubleshooting and FAQs ..............14-15 Exploded View .................... -
Page 4: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS IMPORTANT SAFETY PRECAUTIONS RETAIN FOR FUTURE REFERENCE AND READ CAREFULLY! Do not attempt to install or operate this machine until you have read the safety instructions in this manual. Safety items throughout this manual are labeled with a Danger Warning, or Caution depending on the risk type. - Page 5 5044-036 ELECTRIC PRESSURE WASHER 2300 PSI SYMBOL MEANING DANGER To reduce the risk of fire, electric shock, explosion or injury to people, read the following: • This product is intended for domestic outdoor use only. • The water spray must never be directed towards any electric wiring, devices, or directly towards the pressure washer itself, or fatal electric shock may occur.
- Page 6 SYMBOL MEANING CAUTION - WATER CONNECTIONS • For use with fresh and clean water only. Do not use this product with other liquids. • The water supply system must be protected against back flow. • Never use this product with water contaminated with solvents (e.g.
- Page 7 5044-036 ELECTRIC PRESSURE WASHER 2300 PSI INTENDED APPLICATION This product is designed for specific residential applications. Do not modify or use this product for any application other than the one it was designed for. This equipment was not designed for industrial use. Please refer to the icons below for suggested applications.
- Page 8 • Do not use damaged extension cords. Examine the extension cord before using and replace it if damaged. Do not abuse extension cords and do not pull on any cord to disconnect the device. • Keep cord away from heat and sharp edges. •...
-
Page 9: Unpacking
5044-036 ELECTRIC PRESSURE WASHER 2300 PSI UNPACKING When unpacking this product, check to make sure parts listed below are included and carefully inspect for any damage that may have occurred during transit. If any part is missing and damaged, do not attempt to assemble or use the product. -
Page 10: Preparation Before Operation
PREPARATION BEFORE OPERATION HOW TO SET UP YOUR UNIT 1. To assemble the handle, align both ends of the top handle with the lower handle. Insert the top handle while pressing the spring buttons to allow the handle slide into the lower handle. -
Page 11: Operation
5044-036 ELECTRIC PRESSURE WASHER 2300 PSI OPERATION WARNING The appliance is NOT INTENDED to be used at a temperature under 32°F (0°C). TO START YOUR PRESSURE WASHER 1. Connect pressure washer to water supply - Connect one end of the home garden hose (not supplied) to the water inlet connector and the other end to water source. - Page 12 PUSH IN THE NOZZLE PULL OUT THE NOZZLE 0° nozzle - RED 25° nozzle - GREEN 40° nozzle - WHITE Soap nozzle - BLACK Turbo nozzle 4. Connect the washer to the power supply and turn the switch to “ON/I” position. Then press trigger to start unit for cleaning.
- Page 13 5044-036 ELECTRIC PRESSURE WASHER 2300 PSI TO STOP YOUR PRESSURE WASHER 1. When you are finished, release the trigger, turn the switch to “OFF/0” position. 2. Unplug the power cord from the power outlet. ADDING SOAP Open the soap tank cap and add appropriate detergent. Then put the soap tank cap back on.
-
Page 14: Maintenance
MAINTENANCE WATER FILTER AND NOZZLE CLEANING INSTRUCTIONS A clogged or partially clogged water filter or nozzle can cause significant reduction of water pressure coming out of the nozzle and/or cause the unit to pulsate while spraying. l fi e l l l n i cleaned periodically. -
Page 15: Troubleshooting And Faqs
5044-036 ELECTRIC PRESSURE WASHER 2300 PSI TROUBLESHOOTING PROBLEM SOLUTION Unit will not turn on. Make sure the power washer is in the “OFF” position. Plug in the electrical cord to a grounded 120 volt outlet (no electrical extension cord should be used). -
Page 16: Exploded View
EXPLODED VIEW... -
Page 17: Parts List
5044-036 ELECTRIC PRESSURE WASHER 2300 PSI PARTS LIST Key # Part Code Part name Quantity BUAK041001 Cap nut M6 BUAK041002 Cross pan head bolt M6×42 BUAK041003 Snap button BUAK041004 Canada power cord BUAK041005 Right bracket BUAK041006 Rocker cover BUAK041007 Crank... - Page 18 BUAK041033 Through pin 0.6 BUAK041034 Lotus sprinkler BUAK041035 M22 high pressure hose BUAK041036 P10 upper platen BUAK041037 Air outlet filter BUAK041038 Motor pump BUAK041039 P10 lower platen BUAK041040 Left bracket BUAK041041 Lower shell BUAK041042 Bayonet BUAK041043 Three-way bushing joint BUAK041044 Cross recessed pan head screw M6×10 BUAK041045 Split ring Ø8...
-
Page 19: Warranty
WARRANTY BENCHMARK HIGH PRESSURE WASHER If this Benchmark tool fails due to a defect in material or workmanship within three years from the date of purchase, it has a 3-year repair warranty with the original bill of sale. This warranty does not include expendable parts including but not limited to blades, brushes, belts, light bulbs and/or batteries. - Page 20 ELECTRIC PRESSURE WASHER 2300 PSI 3 Year Limited Warrant 5044-036 BENCHMARK TOOLS CANADA Made in China ST. JACOBS, ONTARIO N0B 2N0 © 2022 Home Hardware Stores Limited CUSTOMER SERVICE/TECH SUPPORT 1-866-206-0888 * This Benchmark product carries a three (3) year LIMITED warranty against defects in workmanship and materials.
