- Page 1 Refrigerated bath basic units Original operating manual 1.950.0170.us.V07 05/2022...
- Page 2 Legal JULABO USA, Inc. 884 Marcon Boulevard Allentown, PA 18109 Phone: +1(610) 231-0250 Fax.: +1(610) 231-0260 Info@julabo.us www.julabo.us The content of this operating manual is protected by copyright. Information, including texts, images, and other contents may not be reproduced, distributed, transmitted, stored or otherwise used in any form without prior explicit written consent.
-
Page 3: Table Of Contents
Foreword ..................... 4 About this manual ................5 Notes on commissioning and operation .......... 5 Original JULABO spare parts ............5 Accessories ..................5 Warnings ..................6 Symbols used .................. 7 Intended use ..................7 Safety ....................8 General Safety Instructions for the operating company ....8 General Safety Instructions for the operator ........ -
Page 4: Foreword
Foreword Congratulations! You have made an excellent choice. JULABO would like to thank you for the trust you have placed in our company and products. This operating manual will help you become acquainted with the use of our units. Read the operating manual carefully. Keep the operating manual handy at... -
Page 5: About This Manual
Read the Safety section of this manual before using the equipment for the first time. Notes on commissioning and operation The cooling machine is combined with a suitable JULABO circulator to form a refrigerated circulator. Operation is done entirely via the control elements of the connected circulator. -
Page 6: Warnings
About this manual Warnings The manual contains warnings to increase safety when using the device. Warnings must always be observed. A warning sign displayed in signal color precedes the signal word. The signal word, highlighted in color, specifies the severity of the hazard. CAUTION This signal word designates a danger with a low level of risk which, if it not prevented, may result in minor to moderate injuries. -
Page 7: Symbols Used
This is a laboratory device intended for temperature control applications of liquid media. It can only be operated in conjunction with a JULABO circulator designed for this purpose. Only use the device if it is in technically perfect condition and only use it in accordance with its intended use. -
Page 8: Safety
Safety Safety General Safety Instructions for the operating company This section outlines the General Safety Instructions that must be observed by the operator to ensure safe operation. • The operator is responsible for the qualifications of its operating personnel. • The operator must ensure that the operating personnel has been instructed in use of the device. -
Page 9: General Safety Instructions For Device Operation
• Exchange and disposal of used refrigerant may only be carried out by JULABO or an appropriately certified company. • All laws and guidelines for handling refrigerants applicable in the country of operation must be complied with. -
Page 10: Safety Symbols
Safety Safety symbols There are safety symbols included with the device, which should be attached to the device before initial operation. Safety Description symbols Warning of a danger zone. Note operating manual Warning about hot surface Read operating manual before switching on Produc t des cripti on... -
Page 11: Product Description
The cooling machine is controlled by the connected circulator. Possible combinations with circulators The table lists which cooling machine can be combined with which circulator. Cooling Circulators machine CORIO CD CORIO CP DYNEO DD MAGIO MS 200F 201F 300F ... -
Page 12: Operating And Functional Elements
Product description Operating and functional elements The following figure shows the operating and functional elements and their position on the unit. Front (without cover) and rear (e.g. 310F) Recessed grip Bath tank drain opening Drain valve Drain hose (for 310F and 450F) Condenser Recessed grip CAN plug for connection with a circulator... -
Page 13: 5.3.1 External Inverter
Product description 5.3.1 External inverter With the 100 V voltage variant of 310F and 450F, the inverter is mounted on the rear side. Rear side of 310F/450F (100 V voltage variant) Inverter CAN plug for connection with a circulator Mains input socket Circulator mains output socket Mains fuse Mains fuse... -
Page 14: Technical Data
Product description Technical data Performance specifications measured in accordance with DIN12876. Cooling capacities up to 20°C measured with ethanol; over 20°C with thermal oil unless specified otherwise. Performance specifications apply at an ambient temperature of 20°C. Performance values may differ with other bath fluids. Grouping of the device acc. - Page 15 Product description Technical data 200F Performance values Lowest temperature °C Refrigerants R134a Dimensions Dimensions (W x D x H) 23 x 39 x 44 Usable bath opening (W x D) 13 x 15 Bath depth Volumes min. … max. 3.0 … 4.0...
- Page 16 Product description Technical data 310F Performance values Lowest temperature °C Refrigerant R449A/R290 Dimensions Dimensions (W x D x H) 23 x 40 x 43 Usable bath opening (W x D) 13 x 15 Bath depth Volumes min. … max. 3.0 … 4.0 Weight Mains connection 100 V...
- Page 17 Product description Technical data 600F Performance values Lowest temperature °C Refrigerants R449A, R452A* Dimensions Dimensions (W x D x H) 33 x 47 x 47 Usable bath opening (W x D) 22 x 15 Bath depth Volumes min. … max. 5.0 …...
- Page 18 Product description Technical data 900F Performance values Lowest temperature °C -38/-40* Refrigerants R449A Dimensions Dimensions (W x D x H) 39 x 62 x 53 Usable bath opening (W x D) 26 x 35 Bath depth Volumes min. … max. 21.0 …...
- Page 19 Product description Technical data 1001F Performance values Lowest temperature °C Refrigerants R449A Dimensions Dimensions (W x D x H) 45 x 64 x 74 Usable bath opening (W x D) 35 x 41 Bath depth Volumes min. … max. 42.0 … 56.0 Weight 70.7 Mains connection...
-
Page 20: 5.4.1 Material Of Parts That Come Into Contact With The Medium
Product description 5.4.1 Material of parts that come into contact with the medium The table lists parts that could come into contact with the bath fluid as well as the material that the parts are made of. This data can be used to check the compatibility of the parts with the bath fluid used. -
Page 21: Transport And Installation
Transport and installation Transport and installation This section describes how to transport the unit safely. CAUTION Risk of crushing by falling device! A device that is not secured appropriately can fall down during improper transport and cause crushing injuries. • Secure the device against tipping and falling during transport •... -
Page 22: Maintenance
Insufficiently dimensioned power cords must not be used. See type plate for mains voltage and current value. We recommend only using original JULABO spare parts. Check safety symbols The following section applies only to equipment working with natural refrigerants and operated in the US or Canada. - Page 23 [3] Note (order no.: 3.383.2640): 1. Check the safety signs on the device for legibility and completeness. 2. Replace defective or missing safety signs. Safety signs can be reordered from JULABO. The safety signs on the device have been checked.
-
Page 24: Emptying
Maintenance Emptying The device must be completely drained if it is to be sent in for technical service or is to be properly disposed of. In general, the device should be completely emptied before longer shutdowns or when there is a change to the external application. CAUTION Risk of burns from hot bath fluid! Bath fluid can become very hot during a temperature control process. -
Page 25: Clean Device
Maintenance Clean device The outside of the device should be periodically cleaned. Lint-free cloth Mild cleaning agent NOTE Damage to the electronics due to water penetration! Ingress of water can damage electronic components of the device and thus lead to failure of the device. -
Page 26: Technical Service
4. Place the venting grid back on. The condenser is cleaned. Technical Service If the unit shows faults you cannot resolve, please contact our Technical Service. JULABO Technical Service Tel.: +1(610) 231-0250 Option 3 Fax: +1(610) 231-260 Email: Service@julabo.us... -
Page 27: Warranty
Warranty The following Warranty Provisions shall apply to products sold in North America by Julabo (“Seller”) to the entity shown as buyer (“Buyer”) on Seller’s invoice. Initial Warranty Upon Seller’s receipt of payment in full for the products and subject to Buyer’s... - Page 28 Maintenance be extended. All repairs or replacements performed by Seller pursuant to these Warranty Provisions shall be performed at one of the Seller’s facility in Allentown, Pennsylvania, U.S.A. or at the facility of an authorized representative of Seller, which location shall be determined by Seller in its sole discretion; provided, however, that Seller may, in its sole discretion perform such repairs or replacements at Buyer’s facility in which case Buyer shall pay Seller’s travel, living and related expenses incurred by Seller in performing the repairs or...
- Page 29 The same exclusions that apply to the regular warranty also apply to OBF classification. For example, JULABO will not be liable for transport damage, damage inflicted by the customer or any other party, or defects arising from improper installation or...
-
Page 30: Disposal
Disposal Disposal When disposing of the device, the applicable country-specific guidelines must be observed. CAUTION Risk of fire with flammable refrigerants! If the device contains a flammable refrigerant, there is a risk of fire if refrigerant leaks. • Do not open the refrigerant circuit •...
