Summary of Contents for Makita DF333DWYE
- Page 1 INSTRUCTION MANUAL Cordless Multi Cutter CP100D Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model: CP100D No load speed 300 min Overall length 291 mm Rated voltage D.C. 10.8 V - 12 V max Standard battery cartridge BL1015 / BL1016 / BL1020B / BL1021B / BL1040B / BL1041B Charger DC10SA / DC10SB / DC10WC / DC10WD Net weight 0.72 - 0.88 kg •... - Page 3 Prevent unintentional starting. Ensure the Battery tool use and care switch is in the off-position before connecting Recharge only with the charger specified by to power source and/or battery pack, picking the manufacturer. A charger that is suitable for up or carrying the tool. Carrying power tools with one type of battery pack may create a risk of fire your finger on the switch or energising power tools when used with another battery pack.
-
Page 4: Functional Description
CAUTION: Do not install the battery cartridge causing fires, personal injury and damage. It will also forcibly. If the cartridge does not slide in easily, it is void the Makita warranty for the Makita tool and charger. not being inserted correctly. Tips for maintaining maximum Battery protection system battery life Charge the battery cartridge before completely dis- The tool is equipped with a battery protection system. - Page 5 In this situation, turn the tool off and stop the application tool if it starts when you pull the switch trigger that caused the tool to become overloaded. Then turn without pressing the lock-off button. Ask your local the tool on to restart. Makita Service Center for repairs. If the tool does not start, the battery is overheated. In this situation, let the battery cool before turning the tool WARNING: on again. Never disable the lock function or tape down the lock-off button.
-
Page 6: Operation
NOTICE: Before operating the tool, make sure that the blades are in the right position as shown in the figure. ► 1 . Screw 2. Lock pin Remove the lock pin, and then remove the screw and the blade. Attach the new blade with its flat surface facing the tool, then insert the lock pin, and then tighten the screw firmly to secure the blade. Hold the tool firmly. Turn on the tool, then set the blade against the material to be cut, and then move the tool forward. NOTICE: Do not apply excessive force to the tool. -
Page 7: Maintenance
NOTICE: Never use gasoline, benzine, thinner, alcohol or the like. Discoloration, deformation or cracks may result. To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. OPTIONAL ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other... - Page 8 Makita Corporation 885574-0 20170215 www.makita.com...
