Sharp XL-MP8H Service Manual page 31

J103
PHONES
CFW801A
24
1
CNP501
MAIN PWB-A1
1
BK
CNW103
1
CFW801B
SLOT IN MECHANISM UNIT(208)
MECHANISM PWB
CNS103
2 3
GY
2 3
GY
CNS105
5
4
3
2
1
BK
Figure 6-11 WIRING SIDE OF PWB (2/10)
CHASSIS
GND
TO
CHASSIS
POWER PWB-A6
SO102
AC INPUT
SOCKET
POWER TRANSFORMER
COLOR TABLE
B R BROWN
R D (R ) RED
O R ORANGE
Y L YELLOW
G R GREEN
B L BLUE
V L VIOLET
G Y GRAY
WH (W ) WHITE
BK BLACK
PK PINK
6 – 11
3 2
CNP102
1 2 3
CNP103
F101
L101
LINE FILTER
PT1
XL-MP8H
