Sharp XL-MP150 Operation Manual

Micro component system
Hide thumbs Also See for XL-MP150:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
XL-MP130

MICRO COMPONENT SYSTEM

MODEL
XL-MP150
OPERATION MANUAL
Downloaded From Disc-Player.com Sharp Manuals
Thank you for purchasing this SHARP product.
To obtain the best performance from this product, please read this
manual carefully. It will guide you in operating your SHARP product.
XL-MP150 Micro Component System consisting of XL-MP150 (main unit)
and CP-MP150 (speaker system).
POWER/
Accessories
Please confirm that the following accessories are included.
Remote control
1
AM loop antenna
(RRMCGA050AWSA)
(QANTL0005AWZZ)
Note:
Only the above accessories are included.
CD
1
FM antenna
1
(92LFANT1746A)
