Getting Started; 5�1 Setting The Language - Renfert SIMPLEX 3D-Filament-Drucker Setup

5

Getting started

The following chapters describe the workflow that is required for initial startup in order to print an object
en
that is provided on the supplied USB flash drive.
A prerequisite is the assembly of the printer as described above�
In addition, all of the following steps must be carried out in the order described�
The first steps include:
• Basic settings in the SETTINGS menu
- Setting the language
- Setting the temperature unit
- Connecting the printer with a Wi-Fi network
• Leveling the print bed
• Moving the print head manually
• Loading the filament
- Selecting a filament
- Heating the print head
- Drawing in the filament
- Extruding the filament manually
• Calibrating the filament sensor (FMS)
• Loading the model from a USB flash drive
• 3D printing
Additional setting and control options offered by the printer are described in subsequent chapters.
Note on using the menu:
Use the lower left arrow
the main menu.
5.1 Setting the language
A video on this topic is provided under the following link
www.renfert.com/simplex-2-en
⇒ Select the SETTINGS menu.
⇒ Use the right arrow
⇒ Press the button with the language icon
⇒ Use the arrows
⇒ Confirm your selection with OK.
⇒ Press the lower left arrow
to go back one page, exit a setting, cancel an operation, or return to
and via the QR code shown.
�
to go to page 2 (as shown here in the image).
�
/ to select the required language�
until you are back in the main menu�
- 10 -
Fig. 10
Fig. 11
